• Model NO.：HY380
• Load and Unload Mode：Front Discharge
• Walking Mode：Crawler
• Type：Oversize Loader
• Dimension：2206mm* 1160mm* 1233mm
• Length：2206mm
• Width：1160mm
• Height：1233mm
• Bucket Width(K)：1150mm
• Max Working Height：2143mm
• Transport Package：Nude
• Specification：3ton
• Trademark：HYSOON
• Origin：Hunan, China
• HS Code：8456454131
• Production Capacity：100units,Month

1)Size

Dimension

2206mm* 1160mm* 1233mm

Length

2206mm

Width

1160mm

Height

1233mm

Bucket Width(K)

1150mm

Max Working Height

2143mm

Max Dumping Height

1488mm

Max Dumping Distance

348mm

Total Length without Bucket

1752mm

Turn Radius forward Turning

1307mm

2)Engine

Rated Power (KW)

17.1KW(23hp)

Rotating Speed

3600rpm

Noise(Dd)

≤95

3)Hydraulic

Pressure

17Mpa

Operating Load

200kg

Bucket Capacity

0.15m³

Max Lifting Force

375kg

Travel Speed

0-5.5km/h

Weight

890kg

4)Configuration

Engine

23hp American Briggs& Stratton gasoline engine, 3 year international warranty service.

Parts

Imported Italy hydrocontrol valves;

Tires

With engineering tires. Optional: Solid tires, grass tires, track(crawler).

Optional Configuration

Italy joystick system, three pump & valves for Optional: Diesel engine for optional

Operating

With a back pedal plate, standing operating.

3. HY380 Mini Loader Main Features

Operation:
1) Two handles to achieve operation of working, lifting and dumping.

2) 4 wheels drive, suitable for various environment.

3) Safe pedal, stand operating way.

4) 360°  pivot steering. Save space, Flexible and operating easily.

5) Compact design can for any small space working.

6) Quick hitch system makes fastening attachments quickly and eaily.

7) A loader serves several functions. Hy380 can with various attachment for different working need. Quick hitch system,  attachments can be changed quickly and easily.
8) Compare with same kind of products, hy380 mini loader is with higher lifting height.
Easy maintenance:
1) Easy to put oil and replace Air filter, filter, spark plug, etc.

2) Back shrouds can be took easily, parts can be checked by opening upper canopy.

4. Attachment-Digger:
