8ton 6ton 10ton Wheel Loader 12ton

Evangel Industrial (Shanghai) Co., Ltd.
  • Certification：TUV, UL, ISO, RoHS, CE
  • Condition：New
  • Rated Load：5to to 12ton
  • Transmission：Hydraulic
  • Load and Unload Mode：Front Discharge
  • Walking Mode：Wheeled

Base Info

  • Model NO.：ZL50GN
  • Type：Large Loader
  • Product Name：Wheel Loader Large Wheel Loader
  • Transport Package：Stand Export Package
  • Trademark：TOP BRAND
  • Origin：China
  • Production Capacity：1000units,Month

Description

ItemSpecificationUnitRated operating load5000kgBucket capacity2.5~4.5m³Machine weight16900kgDump clearance at maximum lift3150~3560mmReach at maximum lift1100~1190mmWheel base2960mmTread2250mmHeight of hinge at maximum lift height4112mmWorking height(fully lifted)5510mmMax.breakout force170kNHydraulic cycle time-raise6sTotal hydraulic cycle time10.5sMin. turning radius over tyres5950mmArticulation angle35°Gradeability28°Tyre size23.5-25-16PR Overall machine dimension L×W×H7910×3016×3515 ModelWP10G220E21 Rated Power162KwFuel Tank250LHydraulic Tank210LTravel speed-gear(F/R)13/18km/h-gear(F/R)40km/h
Rated operating load6000kgBucket capacity3.0~4.5m³Machine weight20000±300kgDump clearance at maximum lift3170~3750mmReach at maximum lift1200~1360mmWheel base3350mmTread2265mmMax.breakout force205kNHydraulic cycle time-raise5.9sTotal hydraulic cycle time10.9sMin. turning radius over tyres6005mmArticulation angle38°Gradeability28°Tyre size23.5-25 Overall machine dimension L×W×H8505×3220×3515 Rated Power178KwTravel speed-gear(F/R)6/6km/h-gear(F/R)11/11 -gear(F/R)22/22 IV-gear(F/R)34/34km/hNo further information of sample contents, product structure and configuration parameters updates.There maybe some difference between sample books and material objects.Please kind prevail.

Rated bucket capacity

4.5m3;

Rated load

8000kg

Operating weight

28500kg

Min. clearance

480mm

Max. traction

245kN

Max.drawing force

260kN

Boom lifting time

6.9s

Total time of three devices

11.8s

Engine

Model

QSM11-C335

Type

Electrical injection, turbo charging, air-air intercooling

Rated power

250kW

Rated rotary speed

2100r/min

Travel speed

Forward/Backward I Gear

7/7km/h



Forward/Backward II Gear

11.5/11.5km/h



Forward/Backward III Gear

24.5/24.5km/h



Forward IV Gear

35.5km/h

Tyre model

29.5-25-22PR


Wheel Loader Front End Loader Payloader 12ton

Item

Parameter

Unit

Rated load

12

t

Bucket capacity

6.5

m³

Dumping height

3728

mm

Dumping distance

1861

mm

Operating weight

48000

kg

Dimension (Length × Width × Height )

11280×3886×4250

mm

EngineRated power

391

kW



8ton 6ton 10ton Wheel Loader 12ton

8ton 6ton 10ton Wheel Loader 12ton

Tell me your requirements and we will recommend suitable models and brands for your selecction.
As a professional exporter of all kinds of construction machinery with 10 years experience, we will try our best to make you feel satisfied.
