• Model NO.：L936L
• Type：Medium-sized Loader
• Load and Unload Method：Front Discharge
• Overall Working Weight：10900kg
• Rated Bucket Capacity：1.8cbm
• Load：3000kg
• Dimension：7230*2520*3170mm
• Transport Package：1 Unit Fit in One 40 Hq Container
• Specification：CE
• Trademark：SDLG
• Origin：Shandong, China
• Production Capacity：5000 Units Per Year

ItemPerformanceItemPerformance
Standard bucket capacity (m 3 )1.8
Min. turning radius outside rear wheel(mm)5381
Rated load(kg)3000
Min. turning radius outside bucket(mm)5912
Max. traction force(by engine)(kN)≥ 105
Max. breakout force(kN)≥ 96
Static tipping load(kN)≥ 66
Grade ability(° )30
Travel speedSpeeds1234Forward(km/h)0~130~38_ __ _Reverse(km/h)0~17_ __ __ _
2, Dimension and weight

Item	Performance	Item	Performance
Length(With bucket on ground)(mm)	7100	Bucket width(mm)	2510
Height(mm)	3170	Tread(mm)	1865
Width from outside wheel(mm)	2310	Wheelbase (front/back)(mm)	2850(1250/1600)
Max Dumping height(-45 0 dump angle)(mm)	2950	Operating weight(kg)	10700
Item	1050	Axles	2
Length(With bucket on ground)(mm)	370

3, Engine

Item	Performance	item	Performance
Model	6BT5.9-C120	Cylinder No.	6
Type	Straight-lined, water cooled, direct injection	Cylinder bore/stroke(mm)	102/120
Rated power(/kW)	87	Min fuel consumption ration(g/kW. h)	≤ 217
Rated rmp(r/min)	2200	Max torque (N. m)	436
Displacement(ml)	5.9	Emission standard	JB/T8891
