Grapple Bucket CE Mini Loader (HQ908) with Perkins Engine
Weifang Haiqin Top Machinery Co., Ltd.- After-sales Service：24 Hours Every Day Technology ,Spare Parts Service
- Warranty：1 Year
- Type：Universal Type
- Transmission：Hydraulic Transmission
- Walking Mode：Wheeled
- Load and Unload Method：Front Discharge
Base Info
- Model NO.：HQ908
- Engine Power：18.5kw
- Certification：CE, ISO9001: 2000, SGS,Rops&Fops
- Condition：New
- Color：According to Customers Requirments
- Engine：Perkins
- Operating Weight：1490kg
- Max Loading Weight：800kg
- Width：950mm,1110mm
- Transport Package：3 or 4 Units in One 20 Feet Container
- Specification：CE, ISO, SGS, Rops&Fops
- Trademark：Haiqin
- Origin：Shandong, China
- HS Code：84295100
- Production Capacity：6000 Units , Year
Description
Enginemodel Perkins 403D-11 type 3 cylinder, watercooled rated power 18.5kw rated speed 2800r/min displacement 1.1L max.torque 67Nm Performance drive pump type closed piston pump total weight 1490kg Tipping loads in bucket(kg) lift frame horizontal/machine stright 850 lift frame horizontal/machine articulated 550 rated bucket capacity 0.35M3 - 0.5 M3 overall size 3650×950/1110×2250mm travel speed 0-12km/h max.breakout force 12Kn battery 43Ah rated voltage 12v steering type articulated hydraulic steering drive system hydrostatic motor drive type 4 wheel drive(4WD) transmission model HST transmission type CVT drive axle model hydrostatic drive axle max.grade ability 20° optional tyre 7.00-12 26×12.00-12 or 27*8.5-15 fuel tank capacity 32L hydraulic oil tank capacity 40L
