New Brand Crawler Excavator Xe215c
Evangel Industrial (Shanghai) Co., Ltd.- Type：Universal Type
- Transmission：Hydraulic Transmission
- Walking Mode：Wheeled
- Load and Unload Method：Front Discharge
- Engine Power：<74kw
- Certification：CE, ISO9001: 2000
Base Info
- Model NO.：XE215C
- Condition：New
- Color：Yellow
- Dimension：6155*2320*2635
- Overall Weight：7460kg
- Rated Bucket Capacity：3.0m 3
- Tipping Load：8300kg
- Max.Traction：150kn
- Max.Drawingforce：130kn
- Total Time of Three Devices：10.5s
- Engine：Isuzu
- Warranty：1 Year
- Transport Package：Nude
- Specification：CE
- Origin：Jaingsu China
- HS Code：84295100
- Production Capacity：50, 000PCS,Year
Description
Model XE15 XE40 XE50C XE60CA XE65CA XE80C Operating weight kg 1640 4050 5030 5960 5960 8270/7870 Standard bucket capacity m³ 0.044 0.14 0.18 0.09-0.23 0.09-0.25 0.14-0.34 Engine Model / 3TNV82A 4TNV88 4TNV88-SYY 4TNV94L 4TNV94L B3.3 Direct injection / √ √ √ √ √ √ 4 Four strokes / √ √ √ √ √ √ Water cooling / √ √ √ √ √ √ Turbo charged / × × × × × √ Air to air intercooler / × × × × × × No. of cylinders / 3 4 4 4 4 4 / Rated power/speed kw/rpm 16.5/2200 27.1/2200 37.6/2200 39.8/2200 39.8/2200 60/2200 / Max. torque/speed N.m 86.5/1320 142/1320 142 214/1100 214/1100 292/1600 Displacement L 1.33 2.19 2.19 3.054 3.054 3.3 Travel speed km/h 4.4/2.4 4.2/2.6 4.2/2.6 4.2/2.2 4.2/2.2 4.9/2.6 Swing speed r/min 11 13.5 13.5 11 11 12 Max. gradeability / 30 30 58% 30 30 35 Ground pressure kPa 23.8 36.3 29.5 32.5 32.5 35 Max.Bucket digging force kN 13.9 23.2 23.2 48.3 48.3 53.6 Max.arm crowd force kN 8.8 19.3 19.3 32.5 32.5 39.2 Max.traction force kN 12.2 33.9 -- -- -- 59 Main pump / -- -- Rate flow of main pump L/min 2×19.8+14.1 1×110+11 2×55+11 143 156.2 1×198+21 Max pressure of prime relief valve MPa 24 21 21 24.5 24.5 27.4 Max pressure of travel system MPa 21 21 21 22 22 27.4 Max pressure of swing system MPa 18 21 16.7 21 21 20.6 Max pressure of pilot system MPa 3.3 3.9 3.9 3.5 3.5 3.9 Fuel tank capacity L 20 65 65 110 110 127 Hydraulic tank capacity L 29 70 70 85 85 124 Engine lubrication L 5.5 7.4 7.4 12 12 7 A Overall length mm 3760 5455 5475 5860 5860 6155 B Overall width mm 1080 1650 1800 1920 1920 2320 C Overall height mm 2400 2440 2540 2585 2585 2635 D Overall width of upperstructure mm 1080 1500 1500 1780 1780 -- E Overall width of undercarriage mm 1080 1635 1800 1920 1920 2320 F crawer width mm 230 300 400 400 400 450 G Tumbler distance mm 1217 1721 1917 1990 1990 2180 H Crawer gauge mm 850 1335 1400 1500 1500 1870 I Clearance under counter weight mm 472 578 675 710 710 821 J Ground clearance mm 180 350 381 385 385 428 K(/)Dozer black(width/height) mm 1080/225 1650/300 1800/340 1920/340 1920×340 -- A Max. digging height mm 3616 5320 5412 5630 5630 7188 B Max. dumping height mm 2478 3700 3788 3945 3945 5100 C Max. digging depth mm 2320 3600 3555 3830 3830 4119 D Max. vertical wall digging depth mm 1520 2580 3115 2680 2680 3197 E Max. digging reach mm 3915 5810 5810 6130 6130 6375 F Min. swing radius mm 2335 2385 2385 2460 2460 -- G Min.tail swing radius mm 1190 1490 1490 1660 1660 1770 Max.dozer lifting height mm 220 255 718 390 390 409 Max.dozer cutting depth mm 240 375 560 560 560 438 mm 1690 2795 2795 3000 3000 3710 mm 1100 1600 1600 1600 1600 1650 m³ 0.044 0.14 0.18 0.23 0.25 0.34 m³ / / / 0.2 0.2/0.23 0.3 m³ / / / 0.09 0.09 0.14
