• Model NO.：8125GL
• Travel Speed：8km,H
• Centrifugal Force：30.5KN
• Certification：ISO 9001:2000, ISO 9001:2008
• Condition：New
• Operating Weight：12 Ton
• Theoretical Gradeability：20%
• Power：60kw
• Static Line Load：277n,Cm
• Transport Package：Seaworthy Packing
• Specification：ISO
• Trademark：Changlin
• Origin：Jiangsu, China
• Production Capacity：60000 PCS,Month

Basic Info.

Model NO. 8125GL Travel Speed 8km/H Centrifugal Force 30.5KN Certification ISO 9001:2000, ISO 9001:2008 Condition New Operating Weight 12 Ton Theoretical Gradeability 20% Power 60kw Static Line Load 277n/Cm Transport Package Seaworthy Packing Specification ISO Trademark Changlin Origin Jiangsu, China Production Capacity 60000 PCS/Month

Product Description

12 Ton Changlin Road Roller Steel Double Drum Vibration Roller

Features
Mechanical travel drive of side transmission, hydraulic vibration and steering with three gears travel speed for convenient transport between construction sites.

Dual operator seats and dual steering wheels with good sight line of side compacting.

The machine adopts DF Cummins engine with large power reservation, low fuel consumption, good performance of exhaust and good starting feature.

Electric controlled water spraying on front and rear drum surfaces.


Specifications
Operating Mass: 12000kg
Static Line Load: 277/338N/cm
Vibration Amplitude: 0.35mm
Vibration Frequency: 48HZ
Centrifugal Force: 120kN
Traveling speed: 8 (km/h)
Gradient capacity: 20%
Turning Radius: 7000mm
Drum Width: 1300mm
Drum Diameter: 1950mm
Wheelbase: 3240mm
Ground Clearance: 300mm
Diesel Engine Model: 4BTA3.9-C80
Diesel Engine Power: 60Kw
Ovewall Dimensions: 5540*2396*3000
