• Model NO.：FR330D
• Drive Type：Internal Combustion Drive
• Bucket Capacity：>1.5m³
• Size：Large-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Operating Weight：37700kg
• Model：Fr330d
• Output Power：190.5,2000(Kw,Rpm)
• Displacement：7.79L
• Travel Speed(H/L)：4.9km,H
• Gradeability：35
• Maximum Digging Height (mm)：10120
• Maximum Dumping Height (mm)：7400
• Transport Package：Nude Package
• Specification：11366*3202*3505mm
• Trademark：MAXIZM
• Origin：Qingdao, China
• HS Code：8429521200
• Production Capacity：1000,Momth

Overview Product Description

Product Parameters



Operation Weight (Standard Configuration) (KN)33600Standard Bucket Capacity1.5Rated Power/Rotate Speed (KW/rpm)190.5/2000Transport Dimensionsmm11303*3202*3290Bucket Digging Force (KN)205Bucket Rob Digging Force (KN)155Maximum Traction (KN)290DeviceMax. Walking Speed (Km/h)4.9Climbing Performance(°)35Total Length of the Crawler4600Minimum Revolving Radius (mm)4320Width of the Crawler600Ground Pressure (Kpa)68Turning MechanismTurning Speed (rpm)9.2EngineModelISUU AA-6HK1XQPTypeFour Strokes, Water-cooling, Straight, Turbocharger, Inter CoolingRated Torque/Rotate Speed (N.m/rpm)872.8/1700Cylinder Diameter*Stroke (mm)115*125Output Value (L)7.79Fuel Consumption (g/KW.h)237Fuel Tank Capacity (L)630Hydraulic SystemMain Pump Pressure (Mpa)37Main Pump Flow Operating ScopeMaximum Digging Height (mm)10120Maximum Dumping Height (mm)7400Maximum Digging Depth (mm)7330Maximum Digging Radius (mm)11075
