Shantui 21ton Crawler Digger Excavator Se210-9 Se220

Maxizm Construction Machinery (Qingdao) Co., Ltd.
  • After-sales Service:-
  • Warranty:12 Months
  • Type:Crawler Excavator
  • Usage:Mining Excavator
  • Bucket:Shovel
  • Transmission:Hydraulic Transmission

Base Info

  • Model NO.:SE210
  • Drive Type:Diesel
  • Bucket Capacity:0.5~1.0m³
  • Size:Medium-Sized
  • Certification:CE, ISO9001: 2000
  • Condition:New
  • Product Name:Se210-9
  • Maximum Digging Height (mm):10095
  • Maximum Dumping Height (mm):7190
  • Maximum Digging Depth (mm):6490
  • Maximum Vertical Digging Depth (mm):5915
  • Maximum Digging Distance (mm):9860
  • Engine Displacement (L):5.9L
  • Type of Hydraulic Pump:Variable Displacement Plunger Pump
  • Rated Working Flow (L/Min):2X218L,Min
  • Bucket Capacity (M3):0.90m3 (SAE)
  • Transport Package:Nude
  • Specification:5855mm*1880mm*2060mm
  • Trademark:Famous
  • Origin:China
  • HS Code:84295212
  • Production Capacity:2000,Year

Description

Comparative itemSE210-9Overall dimensions Overall length (mm)9625Ground length (During transport) (mm)4915Overall height (To the top of boom) (mm)3075Overall width (mm)2800Overall height (To top of cab) (mm)3055Ground clearance of counterweight (mm)1075Minimum ground clearance (mm)470Tail turning radius (mm)2925Track length (mm)4140Track gauge (mm)3360Track width (mm)2800Standard track shoe width (mm)600Turntable width (mm)2725Distance from slewing center to tail (mm)2920Working range Maximum digging height (mm)10095Maximum dumping height (mm)7190Maximum digging depth (mm)6490Maximum vertical digging depth (mm)5915Maximum digging distance (mm)9860Maximum digging distance at ground level (mm)9675Working device minimum turning radius (mm)2970Engine ModelDongfeng B5.9-CType6-cylinder inline and water-cooled and turbochargedDisplacement (L)5.9LRated power (kW/rpm)112kW/1950rpmHydraulic system Type of hydraulic pumpVariable displacement plunger pumpRated working flow (L/min)2x218L/minBucket Bucket capacity (m³)0.90m3 (SAE)Swing system Maximum swing speed (r/min)11r/minBrake typeMechanically applied and pressure releasedDigging force Bucket arm digging force (KN)99kN/107KNBucket digging force (KN)135kN/146KNOperating weight and ground pressure Operating weight (kg)20800kgGround pressure (kPa)47.5KPaTraveling system Traveling motorAxial variable displacement plunger motorTraveling speed (km/h)3.15/5.15km/hTraction force (KN)214kNGradeability70% (35°)Tank capacity Fuel tank capacity (L)330LCooling system (L)28LEngine oil capacity (L)22LHydraulic oil tank/system capacity (L)270/400L
