• Model NO.：SWE210E
• Size：7815X2600X2825 mm
• Certification：ISO9001
• Condition：New
• Warranty：2 Years
• Rated Speed：5.4,Km,H
• Hydraulictank：150L
• Maximum Digging Depth：5640mm
• Hydraulic Pump Brand：Kyb
• Operatingweight：14.8t
• Operating Weight：20 Ton
• Moving Type：Crawler Excavator
• Hydraulic Cylinder Brand：Kyb
• Maxdiggingheight：8630mm
• Power：84kw,2200rpm
• Maximum Digging Height：8630mm
• Wheelbase：3000mm
• Max Digging Radius：8355
• Local Service Location：Indonesia
• Specification：20 Ton
• Trademark：SUNWARD
• Origin：Hunan, China
• Production Capacity：100000 Set,Sets Per Year

Size(L×W×H)9590×2800×3045 mm

Outline dimension

A)Wheel-base3465mmB)Crawler length4260mmC)Ground clearance of platform1060mmD)Tail slewing radius of platform2750mmE)Width of upper body2710mmF)Gauge2200mmG)Chassis width2800mmH)Track width600mmI)Chassis ground clearance470mmJ)Cab roof height2965mmK)Transport boom height3045mmL)Transport length9590mm

Operating range

a)Max.digging height9740mmb)Max.dumping height6980mmc)Max.digging depth6690mmd)Max. vertical digging depth6040mme)Max.digging radius9950mmf)Max.digging reach at ground level9785mm

Performance parameters

Operating weight(steel track)21.3tStandard bucket capacity0.95m3Bucket digging force154kNBucket rod digging force110kNTravel speed(Max./Min.)4.9/3.1 km/hGround pressure43.2kPaSwing speed11.8rpmEngineBrandISUZUModel6BGITRP-03Type6-cylinder, 4-stroke, water-cooledPower110kW/2100rpmDisplacement6.494L

Oil tank capacity

Fuel tank370LHydraulic tank250L
