Mobile Concrete Mixer Truck with Self-Loading System
Shanghai Super-Above Industry Holdings Co., Ltd.- Shotcrete Type：Wet
- Machining Process：Hydraulic
Base Info
- Model NO.：SA200MP72
- Structure：Rotor Type
- Productivity：25m²,h
- Feeding Height：1370mm
- Vibrating Amplitude：1.1mm
- Certification：ISO9001: 2000, CE
- Condition：New
- Color：Yellow
- Max. Actual Output：15m3,H
- Max.Theoretical Output：30m3,H
- Max.Outlet Pressure：10m PA
- Distribution Valve Type：S Tube Valve
- Power：45kw
- Unmixed Capacity：560L
- Mixed Capacity：350L
- Drum Capacity：2210L
- Transport Package：Naked in Container
- Specification：ce
- Trademark：Super-above
- Origin：Jiangsu, China
- HS Code：847431000
- Production Capacity：5000PCS,Year
Description
Linuo mixer pump items
Model
C3
Actual output
m3/h
15-30
Theoretical output
m3/h
30
Max pressure on concrete
Mpa
8
The type of distribution valve
S tube valve
Delivery cylinder
mm
200
Oil tank capacity
L
170
Outlet opening diameter
mm
180
Inner dia of delivery pipe
mm
125
Power
KW
30+8+0.55+5.5=44.05
Max diameter of aggregates
mm
40
Maximum delivery horizontal distance
m
200
Maximum delivery Vertical distance
m
70
Capacity of charge hopper
L
650
Capacity of discharge hopper
L
800
Diameter of drum
mm
1440
Drum rotary speed
r/m
15
Mixing time
s
15
Dimension
mm
5200*2100*3100
Weight
kg
5500
Quantity in 20ft container
set
1
Product Feature
1) Better stability
The pump adopts Kawasaki hydraulic pump and import group valve to better stability and longer service life.
2) Strong transfer capability
With Dia.200mm transfer pipe, the pump can transfer more concrete and deal with an aggregate diameter is 40mm.
3) Lager hopper
With 0.65m3 hopper, the dump can be high capability and less surplus.
4) High efficiency
The dump is more automatable, and can save labor. The hydraulic outrigger we adopted in the product can save configuration time
than 3times.15-30m3; Self-Loading Concrete Mixer Pump
