• Model NO.：ZL50G
• Usage：Special Type
• Scraper Type：Tractor-Scraper
• Load and Unload Method：Front Discharge
• Engine Power：74~147kw
• Color：Yellow
• Transport Package：Nude Package
• Specification：CE, ISO
• Trademark：changlin
• Origin：Jiangsu China
• Production Capacity：3000,Month

Overall Dimension
1
Length(with bucket on ground)

C6121 engine


8365(mm)
8215mm
2
Width(to outside of wheels)
2800(mm) 8215mm
3
Bucket width
2946(mm)
4
Height(To the top of the cab)
3450(mm)
5
Wheel base
3350(mm)
6
Tread
2200(mm)
7
Min. ground clearance
450(mm)
Main Technical Specification
1
Rated load
5000(Kg)
2
Operating weight
16300KG
3
Rated bucket capacity
3.0(m3)
4
Max. breakout force
160kN
5
Max. dump clearance
3050(mm)
6
Dump reach
1107(mm)
7
Dump angle at any position
≥450
8
Digging depth(with bucket bottom horizontal)
165(mm)
9
Min. turning radius

(1) Outside of bucket
6675(mm)

(2) Outside of rear wheel
5879(mm)
10
Pivot angle frame
400
11
Oscillating angle of rear axle
+13o
Hi , sincerely with you have a nice day!

This is Eileen, the sales supervisor from Oriemac International Holding Ltd. Our company is specializing on selling various kinds of construction machinery.

As authorized dealer, we specialized in exporting all kinds of constructions made by Chinese famous factory, like XCM~G,SDLG,CHANGLIN,FOTON,LIUGONG,CHENGGONG. Our productions include Truck and special Vehicle, Earthmoving Machinery, Road construction machinery, concrete machinery, drilling machinery, logistics machinery, Mining Machinery, Agricultural Machinery,Spare parts, ungrouped. Our company website is oriemac.en.made-in-china.com
