Caise 2 Ton Mini Wheel Loader with 1.0m3 Bucket CS920
Evangel Industrial (Shanghai) Co., Ltd.- Type：Universal Type
- Transmission：Hydraulic Transmission
- Walking Mode：Wheeled
- Load and Unload Method：Front Discharge
- Engine Power：74~147kw
- Certification：CE, ISO9001: 2000
Base Info
- Model NO.：CS920
- Condition：New
- Color：Yellow
- Rated Loading Capacity：2 Ton
- L/M/H：5080*1650*2680mm
- Engine Rated Power：33
- Rated Bucket Capacity：0.5m3
- Engine：Wuxi Sida
- Rated Loading：1000kg
- Transport Package：Nude Packing
- Trademark：CAISE
- Origin：Jiangsu, China
- Production Capacity：500,Month
Description
Model
CS920
Length*width*height
5580/2050/2780mm
Loading weight
2.0t
Operating weight
5.65t
Max.traction force
45KN
Min.ground clearance
290mm
Turning angle
Left/right 35°
Min turning radius
4600mm
Speed
Forward 1 gear
0-7km/h
Forward 2 gear
0-21km/h
Reverse 1 gear
0-7km/h
Reverse 2 gear
0-21km/h
Engine mode
LR4B3-G90A
Rated speed
60/2400 kw/r/min
Cylinder/dimension/stroke
4/108/125
Bucket capacity
1.0 m3
Max.breakout force
60KN
Circulating time
10S
Dump height
2800mm
Dump clearance
1050mm
tire
16/17-20
Tire width
400mm
track base
1540 mm
wheel base
