Caise 1 Ton Mini Wheel Loader with Ce Certification CS910
Evangel Industrial (Shanghai) Co., Ltd.- Type：Universal Type
- Transmission：Hydraulic Transmission
- Walking Mode：Wheeled
- Load and Unload Method：Front Discharge
- Engine Power：74~147kw
- Certification：CE, ISO9001: 2000
Base Info
- Model NO.：CS910
- Condition：New
- Color：Yellow
- Rated Loading Capacity：1 Ton
- L/M/H：5080*1650*2680mm
- Engine Rated Power：33
- Rated Bucket Capacity：0.5m3
- Engine：Wuxi Sida
- Rated Loading：1000kg
- Transport Package：Nude Packing
- Trademark：CAISE
- Origin：Jiangsu, China
- Production Capacity：500,Month
Description
Model
CS910
(Length*width*height)mm
4450/1430/2370(2000)mm
Loading weight
1.0t
Operating weight
2690kg
Max.traction force
35KN
Min.ground clearance
230mm
Turning angle
35°
Min turning radius
3750mm
Speed
Forward 1 gear
0-7km/h
Forward 2 gear
0-24km/h
Reverse 1 gear
0-7km/h
Reverse 2 gear
0-24km/h
Engine mode
B490BT
Rated speed
32.4/2400kw/r/min
Cylinder/dimension /stroke
4/108/125
Bucket capacity
0.54 m3
Circulating time
9S
Dump height
2420mm
Dump clearance
850mm
tire
10/16.5
Tire width
270mm
track base
1160 mm
wheel base
1710 mm
