• Model NO.：XE200DA
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Operation Weight：21200kg
• Engine Model：Qsb7
• Engine Power：135,2050kw,Rpm
• Max Torque：740,1250kg.M,Rpm
• Travel Speed：5.3,2.9km,H
• Swing Speed：11.6r,Min
• Ground Pressure：46.9kpa
• Bucket Digging Force：149kn
• Overall Width of Chassis：2890mm
• Min. Ground Clearance：486mm
• Transport Package：Nude Package
• Specification：9625x2900x3100mm
• Origin：China
• HS Code：84264910
• Production Capacity：10000

Sales modelUnitXE200DAOperating weightKg21200Bucket capacitym³0.93
EngineModel/QSB7Direct injection/√Four strokes/√Water cooling/√Turbo-charging/√No. of cylinders/6Output powerkw/rpm135/2050Maximum torque/speedN.m/rpm740/1250DisplacementL6.7
Main performanceTravel speedkm/h5.3/2.9Swing speedr/min11.6Gradeability°35Ground pressurekPa46.9Bucket digging forcekN149Arm digging forcekN121Maximum tractionkN184
Hydraulic systemRated flow of main pumpL/min2×209Main safety valve pressureMPa34.3Travel system pressureMPa37Rotary system pressureMPa28Pilot system pressureMPa3.9
Oil CapacityFuel tank capacityL400Hydraulic tank capacityL220Engine oil capacity L24
Appearance sizeOverall lengthmm9625Overall widthmm2900Overall heightmm3100Width of platformmm2830Track lengthmm4155Overall width of chassismm2890Track widthmm600Length to center of rollersmm3366Track gaugemm2290Counterweight clearancemm1050Min. ground clearancemm486Min. tail swing radiusmm2890Track heightmm940
Working scopeMax. digging heightmm9680Max. dumping heightmm6815Max. digging depthmm6460Maximum depth cut for 2240mm(8 ft) level bottommm6275Max. vertical wall digging depthmm5590Max. digging radiusmm9790Min. swing radiusmm3530
Standard configurationLength of boommm5680Length of armmm2710Bucket capacitym³0.93
Optional configurationLength of boomm³/Length of armm³2400Bucket capacitym³
0.9/1.0/1.1 Earth Working bucket
0.9/1.0 Strengthened bucket
