Zl12f Mini Wheel Loader with CE Euro III Engine as Optional (0.6m3, 1.2rated Loading Weight)

Wuhan Kudat Industry & Trade Co., Ltd.
  • Certification：TUV, UL, ISO, RoHS, CE
  • Condition：New
  • Rated Load：1-3t
  • Transmission：Hydraulic
  • Load and Unload Mode：Front Discharge
  • Walking Mode：Wheeled

Base Info

  • Model NO.：ZL12F mini wheel loader
  • Type：Small Loader
  • Rate Load (Kg)：1200
  • Bucket Capacity (M3)：0.6
  • Dump Clearance(Mm)：2650
  • Dump Reach (Mm)：1020
  • Drive Means：Four Wheel Drive
  • Operating Weight (Kg)：3100
  • Overall Dimensions(Length*Width*Height)：4800*1730*2720
  • Engine Model：Changchai 4L68
  • Engine Rated Power (Kw)：37
  • Engine Rated Output (Rpm)：2400
  • Transport Package：Nude Packing
  • Specification：CE
  • Trademark：Kudat
  • Origin：Wuhan
  • HS Code：8429
  • Production Capacity：500PCS,Month

Description

Overall dimensions (Length*width*height) (mm)4800*1730*2720Min. ground clearance (mm)260Dump clearance(mm)2650Engine ModelChangChai 4L68Dump Reach(mm)1020Engine Rated power (kw)37Lifting time of bucket (s)4Engine Rated output (rpm)2400Zl12f Mini Wheel Loader with CE Euro III Engine as Optional (0.6m3, 1.2rated Loading Weight)
