5010 5ton Tower Crane Manufacturer Construction Site Machines
SHANDONG TAVOL MACHINERY CO., LTD.- Condition：New
- Application：Building, Construction
- Rated Max.Load：5ton
- Rated Tip Load：1.0ton
- Free Standing Height：30m
- Max.Lifting Height：120m
Base Info
- Model NO.：QTZ63-5010
- Span：50m
- Mast Section：1.6mx1.6mx2.5m(Angle Steel)
- Electric：Schneider
- Warranty：14 Months From The B,L Date
- Transport Package：40hc Container
- Specification：SGS ISO BV
- Trademark：Tavol
- Origin：Shandong, China
- HS Code：84262000
- Production Capacity：2000sets,Year
Description
QTZ63
Standard Model
5010
Max. Lift Load
5t
Tip Load
1.0t
Free Standing Height
29m
Max.Anchorage Height
120m
Jib Length
50m
Mast size
1.6×1.6×2.5m
Lift Mechanism
Lifting Speed
(a=2) 68/34 m/min
(a=4) 34/17 m/min
Lift motor
18/18/5 kw
Wire rope diameter
12.5 mm
Trolley Mechanism
Trolley speed
39/26 m/min
Trolley Motor
1.5/2.2 kw
Slewing Mechanism
Slewing Speed
0.72 r/min
Slew Motor
3.7 kwx2 units
Jacking Mechanism
Jack Climbing Speed
0.4 m/min
Jack Climbing motor
4 kw
Power
380V/50Hz/3P
Luxury Operate Cabin,Schneider Electric Parts
TAVOL brand crane has been exported to many countries like Bangladesh, Vietnam, Autralia, Ethiopia, Thailand, Singapore, Malaysia, Phillipines, Iceland, Brazil and Kazakhstan and so on. It is a great thing to see lots of TAVOL CRANES are insatlled in different countries.
Also many of customers from different countries come to visit us to establish a long-term business relationship with us.They said because of our crane, their heavy work becomes easy.
They gave much advice to us and we learned a lot from them and then we are growing up together. Now we are not only business partners, but also close friends.
Welcome to visit us at your convenient time!
Let's start our business from your clicking.
FAQ
Please supply more detail to us:
1. Building height or tower crane working height.
2. Wokring range or jib length
3. Max load capacity and tip load capacity.
4. Other Special requirements
