• Model NO.：HY380
• Condition：New
• Color：Yellow
• Operating Load：200kg 441lb
• Max Working Height(H3)：2134mm 84.37 Inch
• Total Height(H)：1233mm 48.54 Inch
• Noise(Db)：≤95
• Pressure(MPa)：17
• Bucket Capacity：0.15m³ 5.33ft³
• Max Lifting Force：375kg 827lb
• Travel Speed：0-5.5km,H
• Operating Weight：890kg
• Max Dumping Distance：348mm
• Transport Package：Nude,Container
• Specification：CE, ISO9001: 2000
• Trademark：SINOHENG
• Origin：China
• Production Capacity：800PCS,Month


ItemHY380With Chevron engineering TyreMetricU.SMax working height(H3)2134mm84.37 inchMax pin height(H2)1844mm74.17 inchMax dumping height(H1)1488mm58.58 inchMax Dumping distance(E)348mm13.7 inchMax Dumping Angel(α3)30º30ºRollback of bucket on ground(α2)25º25ºDeparture angel(α1)11º11ºTotal height(H)1233mm48.54 inchGround clearance(F)118mm4.65 inchWheel base(L1)636mm25.0 inchOverall length without bucket(L3)1752mm69.0 inchTotal width(B2)1160mm45.67 inchBucket width(B1)980mm38.6 inchTotal length with bucket(L)2206mm86.9 inchTurn radius forward turning(R)1307mm51.5 inchEngine  Rated Power(KW) Rotating speed(rpm) Noise(Db)≤95Hydraulic System Pressure(Mpa)17Working Time(s) Raise4.27Dump1.34Lower3.31Operating Load200Kg441LbBucket Capacity0.15m³5.33ft³Max Lifting Force375Kg827LbTravel Speed0-5.5Km/h0-3.4mile/hOperating Weight890kg1958lb
