• Model NO.：YC55
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Width of Bucket：775mm
• Engine Model：Yanmar 4tnv94L
• Engine Power：36.9kw,2200rpm
• Max. Gradeability：58%
• Max. Digging Force of Arm：27kn
• Max. Digging Force of Bucket：37kn
• Traveling Speed：3.9~5.1km,H
• Max. Digging Height：5700mm
• Max. Digging Depth：3935mm
• Max. Digging Radius：6380mm
• Max. Dumping Height：3855mm
• Min. Slewing Radius：2670mm
• Overall Length：6035mm
• Overall Width：1865mm
• Overall Height：2570mm
• Transport Package：Nude
• Specification：5710kg
• Trademark：Yuchai
• HS Code：84295212
• Production Capacity：1000 Units Per Month

Excavator ModelYC55-8Basic parameter    Machine weight 5710kgBucket capacity 0.2m3Width of bucket 775mmPerformance parameter   Engine model Yanmar 4TNV94LEngine power36.9kW/2200rpm Max. Gradeability 58%(30°)Max. digging force of arm27KNMax. digging force of bucket37KNTraveling speed3.9~5.1km/hMax. hauling force 44kNSlewing speed of platform11~13.5rpmOperating parameter   Max. digging height5700mmMax. digging depth3935mmMax. digging radius6380mmMax. digging radius on ground level 6196mmMax. dumping height 3855mmMin. slewing radius 2670mmMax. vertical digging depth3377mmTransportation dimension   Overall length6035mmOverall width1865mmOverall height 2570mmOther Parameter   Width of undercarriage 1865mmLength of track2458mmWidth of track 400mmHeight between undercarriage and ground 360mmHeight between platform and ground 648mmPlatform tail turning radius 1685mmTrack gauge1910mmFuel tank capacity 115LHydraulic oil tank capacity 109L    Type and flow rate of pumpVariable Pump 110+11 L/min
