Chinese Motor Grader for Sale, Gr180 with Lower Price
Evangel Industrial (Shanghai) Co., Ltd.- Type：Grader
- Object：Gravel Road
- Moving Type：Mobile
- Mixing Method：Continuous Drum
- Automatic Grade：Automatic
- Product Capacity：40～400t,h
Base Info
- Model NO.：GR180
- Condition：New
- Weight：15400kg
- Dimension：8900* 2625* 3470mm
- Min. Clearance：430mm
- Transport Package：Nude
- Specification：CE, ISO9001
- Origin：Jiangsu
- Production Capacity：10000,Month
Description
GR180
Engine rated power/rev
140kW/2200rpm
Dimension
8900×2625×3470mm
Weight
15400kg
Distribution weight of front wheel
4620kg
Distribution weight of rear wheel
10780kg
Min. clearance
430mm
Front and rear axle clearance
6219 mm
Front and rear axle clearance
1639mm
Max. steering angle of front wheel
±50°
Max. inclination angle of front wheel
±17°
Max. swing angle
±15°
Frame steering angle
±27°
Min. turning radius
7.3m
Traction
≥79kN
Gradeability
20%
Forward speed
5,8,11,19,23,38 km/h
Reverse speed
5,11,23 km/h
Blade
Max. lifting height
460mm
Max. Digging Depth
500mm
Max.inclination angle
90°
Cutting angle
28°-70°
Rotating angle
360°
Blade length × arc height
