• Model NO.：SE135
• Drive Type：Internal Combustion Drive
• Bucket Capacity：0.5~1.0m³
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Engine Model：Qsf3.8t(China III)
• Transport Package：Roro
• Specification：13500 kg
• Trademark：shantui
• Origin：China
• HS Code：8429521200
• Production Capacity：500,Month

Basic Info.

Model NO. SE135 Drive Type Internal Combustion Drive Bucket Capacity 0.5~1.0m³ Size Small-Scale Certification CE, ISO9001: 2000 Condition New Engine Model Qsf3.8t(China III) Transport Package Roro Specification 13500 kg Trademark shantui Origin China HS Code 8429521200 Production Capacity 500/Month

Product Description

SHANTUI SE135 13ton Crawler Excavator Hot Sale with Hydraulic Pump and Breaker






Product Description



High-end system configuration

The high-performance turbocharged engine with mechanical pump features high power, low fuel consumption, and powerful fuel adaptability. The all-new load-sensing hydraulic system and the over-class high-displacement constant-power pump matches with low pressure loss main valve and large bore pipeline to realize smooth operations and fast response and improve the efficiency by >8.5%.

Firm and durable structural parts

The upper frame adopts the modal analysis technology to realize high firmness and durability while effectively reducing the vibration and noise of machine.

The design of structural parts is comprehensive optimized and the critical load-carrying locations are reinforced to resist against severe working conditions.

The baseplates, side plates, and reinforcement plates of bucket are made of high-strength wear-resistant material to improve the durability of bucket.

Comfortable and convenient operating environment

The colors of the all-injection-molded interior trim parts are effectively matched as per ergonomics to mitigate the operator's visual fatigue.

The cab in high-strength irregular-shaped tubular framework structure features broad forward and backward visions and high working safety and is installed with fire extinguisher, escape hammer, and seat belt.

The high-power A/C system outputs pleasant airflow in three-dimensional manner. The air cushioned seat is adjustable by two-stage slideways. The excellent shock-absorbing and noise-reduction performance can realize a perfect driving/riding comfort.

Highly reliable traveling device

With 30 years of R&D and manufacturing experiences of drive sprockets, idlers, track rollers, carrier rollers, and tracks and with industry's high-end technologies, it's the first choice for excavators.

The mature and high-quality forging and heat treatment processes guarantee stable and reliable quality.

The track rollers of same specification with 7T class are installed to realize high firmness and durability and long life.

Intelligent electronic control and optimal power control

The intelligent control system realizes high match between power system and hydraulic system to improve the working efficiency and reduce the fuel consumption.

The man-machine friendly new generation intelligent electronic control system enables you to master all working status of your machine.

Four preset working modes of P (Heavy-Load), E (Economic), A (Automatic), and B (Breaking Hammer) feature easy switchover.

Convenient maintenances

The washer is installed on the left side of engine compartment to ease the checking and refilling.

The fully openable engine hood is installed with locating mechanism to realize handy and safe opening, large engine compartment space, and easy maintenances.

The electric parts are centrally arranged on the right front tool compartment to ease the checking and maintenance.

The filling of coolant and the replacement of air filter are easily accessible.

Optional equipment of machine

Refueling pump

Cab warning lamp

Cab ceiling lamp

Cab overhead protective net

Cab front upper protective net

Cab front lower protective net

Rubber track

Narrow bucket

Wide bucket



Comparative item	SE135 (Standard version)	SE135W(Weichai engine version)
Overall dimensions
Overall length (mm)	7860	7860
Ground length (During transport) (mm)	4320	4320
Overall height (To the top of boom) (mm)	2800	2800
Overall width (mm)	2500	2500
Overall height (To top of cab) (mm)	2855	2855
Ground clearance of counterweight (mm)	915	915
Minimum ground clearance (mm)	425	425
Tail turning radius (mm)	2380	2380
Track length (mm)	3645	3645
Track gauge (mm)	2000	2000
Track width (mm)	2500	2500
Standard track shoe width (mm)	500	500
Turntable width (mm)	2490	2490
Distance from slewing center to tail (mm)	2375	2375
Working range
Maximum digging height (mm)	8495	8495
Maximum dumping height (mm)	6060	6060
Maximum digging depth (mm)	5490	5490
Maximum vertical digging depth (mm)	4625	4625
Maximum digging distance (mm)	8300	8300
Maximum digging distance at ground level (mm)	8175	8175
Working device minimum turning radius (mm)	2445	2445
Maximum lifting height of bulldozer blade (mm)	-	-
Maximum digging depth of bulldozer blade (mm)	-	-
Engine
Model	QSF3.8T(China III)	WP4.1(China III)
Type	4-cylinder inline and water-cooled and turbocharged	Inline 4-cylinder, high pressure common rail, and water-cooled and turbocharged
Displacement (L)	3.76	3.76
Rated power (kW/rpm)	86/2200	92/2200
Hydraulic system
Type of hydraulic pump	Variable displacement duplex plunger pump	Variable displacement duplex plunger pump
Rated working flow (L/min)	2x130	2x130
Bucket
Bucket capacity (m³)	0.4~0.65(0.55)	0.4~0.65(0.55)
Swing system
Maximum swing speed (r/min)	11.3	11.3
Brake type	Mechanically applied and pressure released	Mechanically applied and pressure released
Digging force
Bucket arm digging force (KN)	70	70
Bucket digging force (KN)	97	97
Operating weight and ground pressure
Operating weight (kg)	13500	13500
Ground pressure (kPa)	41.5	41.5
Traveling system
Traveling motor	Axial variable displacement plunger motor	Axial variable displacement plunger motor
Traveling speed (km/h)	3.25/5.2	3.25/5.3
Traction force (KN)	118	118
Gradeability	70%(35°)	70%(35°)
Tank capacity
Fuel tank capacity (L)	220	245
Cooling system (L)	20	20
Engine oil capacity (L)	12	12
Hydraulic oil tank/system capacity (L)	177/205L	177/205L
