• Model NO.：XG931H
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Small Loader
• Tire Specification：23.5-25
• Dumping Distance：1130mm
• Total Weight：17500kg
• Maximum Brakout Force：170kn
• Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Containe
• Specification：6970*3330*2245 mm
• Trademark：XGMA
• Origin：China
• HS Code：84295100
• Production Capacity：1000 Units, Month

Overview Product Description

1, High Reliability
Upgraded & enhanced front & back frames
Reinforced counterweight
Fully optimized layout of pipes
Waterproof connectors
Improved painting process

2, High Efficiency and Energy Conservation
Patented dual-pump confluence and diffluence technology
Standard models provide the highest dumping height
Small turning radius
Green, turbocharged, intercooled engine

3, Safety
Complete safety signs
Optional ROPS/FOPS cab
Flame retardant materials and EU-certified glass are used in the cab, offering higher safety

4,Comfortable Operation
Ergonomic design for more comfortable operation
Large space in the H-series cab
The low-noise and shock-absorbing cab
Electronic oil level indicator comes as standard
Optional models with adjustable directions

5. Convenient Maintenance
Leading-out grease fitting is convenient for lubrication
The brake caliper is exposed to facilitate servicing
Central electrical control box for easier servicing
Wide-opening hood for easier servicing & maintenance of engine
Convertible fuel tank
Optimized servicing marks

6,Multifunctional
Standard bucket
Rock bucket
Enlarged bucket
Flat sand bucket
Log grapple(single clamping arm)
Log grapple(double clamping arm)
Grass grapple
Snow blade
Side dump bucket
Quick coupling bucket
Quick coupling 4-in-1 bucket
Quick coupling log grapple
Quick coupling fork

Product Parameters



ModelXG931HOverall length(mm)6970Overall height(mm)3330Overall width(mm)2245Wheel base(mm)2750Ground clearance(mm)356Tread(mm)1800Bucket Width (mm)2420Turn radius(mm)5280Min.Turn radius outside of bucket (mm)5860 3930Max. Dumping Height(mm)3060Dumping Reach(mm)1020Digging depth(mm)100 50   Engine modelYC6J125Z-T20Rated power (kw)92Fuel comsumption per hour(g/kw.h )225Rated speed (r/min)2200Max torque(N.m)500Operating Weight (Tonnes)10.8Rated Load(Tonnes)3.2Bucket capacity (m3)1.4-3.0Lifting time/Lifting, dumping and lowering(s)6/10.4Max Breakout force(KN)100Max.drawing force (KN)103Max. turning angle(°)±35°Climbing ability(°)≤ 30 °Fuel tank(L)140Hydraulic tank(L)160Working pressure of steering hydraulic system(MPa)13Working pressure of load hydraulic system(MPa)16Travel speeds(km/h)FORWARD 1ST0~12FORWARD 2ND0~40FORWARD 3RD FORWARD 4TH REVERSE 1ST0~16REVERSE 2ND Gear BoxXGAxleXGImplement pump132Distibuting valveDF25-2CSteering Hydraulic systemBZZ5-500Steering pump90Tyre size17.5-25-12PRAir Conditioning/Anti-mist when idleing√Heating√Radio/Cassette√Bucket and arm raiseing (limit height) Device×Hydraulic Operation system√Seat Buckle√Head lamp √Reversing Alarm (Back vehicle)√ROPS/FOPS× Detailed Photos
