Crawler Excavator Xe135b with High Efficicency
Sinomada Heavy Industry (Changsha) Co., Ltd.- Type：Crawler Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket：Grab Shovel
- Transmission：Hydraulic Transmission
- Drive Type：Electric Drive
- Bucket Capacity：>1.5m³
Base Info
- Model NO.：XE135B
- Size：Medium-Sized
- Certification：CE, ISO9001: 2000
- Condition：New
- Transport Package：Cartons
- Trademark：top brand
- Origin：China
- HS Code：8429521200
- Production Capacity：500000
Description
Model
Unit
XE135B
Operating weight
kg
13800
Standard bucket capacity
m³
0.4-0.52
Engine
Engine Model
/
ISUZU BB-4BG1TRP
Direct injection
/
√
Four strokes
/
√
Water cooling
/
√
Turbo charged
/
√
Air to air intercooler
/
×
No. of cylinders
/
4
Rated power/speed
kw/rpm
69.6/2200
Max. torque/speed
N.m
337.6
Displacement
L
4.329
The main performance
Travel speed
km/h
5.16/3.03
Swing speed
r/min
12.3
Max. gradeability
/
≥35
Ground pressure
kPa
42
Max.Bucket digging force
kN
85
Max.arm crowd force
kN
65
Max.traction force
kN
134
Hydraulic system
Main pump
/
2????
Rate flow of main pump
L/min
2×123
Max pressure of prime relief valve
MPa
31.4/34.3
Max pressure of travel system
MPa
34.3
Max pressure of swing system
MPa
25
Max pressure of pilot system
MPa
3.9
Oil capacity
Fuel tank capacity
L
250
Hydraulic tank capacity
L
130
Engine lubrication
L
14
Overall dimensions
A Overall length
mm
7770
B Overall width
mm
2512
C Overall height
mm
2880
D Overall width of upperstructure
mm
2512
E Track length
mm
3660
F Overall width of undercarriage
mm
2490
G Crawer width
?
500
H Track length on ground
mm
2910
I Crawer gauge
mm
1990
J Clearance under counter weight
mm
964
K Ground clearance
mm
478
L Min.tail swing radius
mm
2294
