• Model NO.：GR1003
• Walking Mode：Wheeled
• Type：Medium-sized Grader
• Rated Power/Speed：75kw(2200r,Min)
• Overall Weight (Standard Configuration)：7500kg
• Wheel Tread：1900mm
• Span Between Front and Rear Axles：5135mm
• Ground Clearance (Front Axle)：550mm
• Tire Specification：16,70-24,13.00-24
• Transport Package：Nude
• Specification：7130*2375*3150 mm
• Trademark：SINOMADA
• Origin：Xuzhou
• HS Code：8451648745
• Production Capacity：100units,Month

ItemGR1003Basic parametersEngine modelWP4.1Rated power/speed75kW/2200rpmOverall dimension (standard)7130x2375x3150Total weight (standard)7500kgTire specification16/70-24/13.00-24Ground clearance (front axle)550mmSpace of front and rear axles5135 mmSpace of middle and rear wheels1900 mmPerformance
parametersForward velocity5,8,11,17,24,38km/hReverse speed5,11,24km/hTractive effort f=0.7539 kNMaximum gradeability25%Tire inflation pressure300kPaWorking system pressure16MPaTransmission pressure1.3-1.8MpaWorking parametersMaximum steering angle of front wheel±49°Maximum slant angle of front wheel±17°Maximum oscillating angle of front axle±15°Maximum oscillating angle of equilibrium box±16°Maximum steering angle of frame±27°Minimum turning radius6mScrape knifeMaximum lift height310mmMaximum cutting depth350mmMaximum tilt angle45°Cutting angle28°-70°Angle of revolution120°Length & chord height3048x450mmOil filling amountCoolant50LFuel tank280LEngine18LTransmission26LEquilibrium box/Drive alex28LHydraulic oil89L
