Cost Price Selling 5t Lw500fn Hydraulic Wheel Loader with High-End Configuration

Fujian Raygoo Machinery Co., Ltd.
  • After-sales Service：Shipping Service, Aftermarket Parts Provide
  • Warranty：1 Year
  • Certification：TUV, UL, ISO, RoHS, CE
  • Condition：New
  • Rated Load：3-6t
  • Transmission：Hydraulic

Base Info

  • Model NO.：LW500FN
  • Load and Unload Mode：Front Discharge
  • Walking Mode：Wheeled
  • Type：Medium-sized Loader
  • Rated Bucket Capacity：2.5-4.5m3
  • Engine Power：162~515kw
  • Engine：Weichai & Shangchai & Zf
  • Maximum Breakout Force：170kn
  • Total Weight：17500 Kgs
  • Scraper Type：Tractor-Scraper
  • Model：Wd10g220e21
  • Transport Package：Container, RO-RO
  • Specification：8225*3016*3515mm
  • Trademark：Raygoo
  • Origin：Fujian, China
  • HS Code：87059091
  • Production Capacity：5000

Description

Overview Product Parameters



Rated operating loadkg5000Bucket capacitym³2.5~4.5Machine weightkg16900Dump clearance at maximum liftmm3150~3560Reach at maximum liftmm1100~1190Wheel basemm2960Treadmm2250Height of hinge at maximum lift heightmm4112Working height(fully lifted)mm5510Max.breakout forcekN170Hydraulic cycle time-raises≤6Total hydraulic cycle times≤10.5Min. turning radius over tyresmm5950Articulation angle°35Gradeability°28Tyre size 23.5-25-16PROverall machine dimension L×W×Hmm7910×3016×3515Model WD10G220E21Rated PowerkW162Fuel TankL250Hydraulic TankL210Travel SpeedI-gear(F/R)km/h13/18II-gear(F/R)km/h40 Our machines advantages

Why choose RAYGOO GROUP

1. Quality assurance
2. Multi-currency payment ( RMB / USD / EUR) & Multi Payment team: T/T, L/C at sight....
3. Cheap shipment costs, Rich container package & Fast shipment:
Raygoo group cooperated with many shipping company many years, which can get the cheapest ocean freight with latest shipping date, even whole shipping tracking.
Cost Price Selling 5t Lw500fn Hydraulic Wheel Loader with High-End Configuration
4. Long-term spare parts support:
Since 2015, in order to effectively solve our customers spare parts demand, we built a spare parts department, which get high speaking feedback from our clients.
Cost Price Selling 5t Lw500fn Hydraulic Wheel Loader with High-End Configuration
5. Long-term technical service support:
We have a professional technical team which provide technical support for our domestic or oversea clients. If clients have some technical problems which can't deal with it by self, we can provide video support or door to door support.
6. Door and door service:
Till now, we can support door and door assembling service if they can't assemble it when container arrived in some countries,such as Philippines, Zimbabwe, Mozambique, Kenya, Cambodia, Indonesia.... If the quantity is large, even can provide engineer indoor support.
Cost Price Selling 5t Lw500fn Hydraulic Wheel Loader with High-End Configuration
Cost Price Selling 5t Lw500fn Hydraulic Wheel Loader with High-End Configuration
7. Rich brands:
As we worked on construction machines more than 15 years, which already build nice strategic relationship with world brand company for competitive price and quality.support
