• Model NO.：SD9
• Condition：New
• Color：Yellow
• Weight：48888kg
• Dozing Capacity：13.5cbm
• Dimension(Long * Breadth * High)：5037×3297×3077mm (Without Ripper)
• Engine：C6121 Diesel Engine
• Engine Type：Inline, 6-Cylinder, Turbocharged, Water-Cooled
• Rated Power：316kw
• Torque Converter：3-Element, Single-Stage, Single-Phase
• Ground Clearance：517 mm
• Track Gauge：2250 mm
• Pump：Double Vane Pump
• Transport Package：Nude, Suitable for Shiping
• Specification：ISO
• Trademark：HBXG
• Origin：Hebei, China
• HS Code：84291190
• Production Capacity：1000sets,Month

EngineModel KTA19-C525 or  QSX15TypeInline, 6-cylinder, turbocharged, water-cooledFlywheel power, kW316Rated speed, r/min1800Transmission systemTorque converter3-element, single-stage, single-phaseTransmissionHydraulic shift, planetary gear, hydraulic-actuated, multiple-disc clutch, forced lubrication, 3 forward and 3 reverse speedsBevel gearHelical bevel gear, one reduction, splash lubricatedSteering clutchWet, multiple-disc, spring loaded, hydraulically operated and releasedSteering brakeWet, band brake, operated with hydraulic booster and valve inner linkageFinal driveSpur gear, double reduction, splash lubricatedTravel speed, km/hForward: 1st3.92nd6.73rd12.2Reverse: 1st4.82nd8.53rd15.1Under carriageSprocketSegmentedTrack tensionHydraulic-adjustedNumber of track shoes, each side7Number of carrier rollers, each side1* Floating seals are used in all track rollers, carrier rollers, sprocket and front idlersTrackTypeSealed and lubricated trackTrack pitch, mm240Track width, mm610Ground clearance, mm517Track gauge, mm2250Ground pressure, MPa0.102Gradeability, °latitude 30° / transverse 25°Hydraulic system of work equipmentWorking pressure, MPa18.3Rated flow (at 1800 r/min), L/min300PumpDouble vane pumpValve positionRaise, hold, lower, floatWork equipmentBlade typeS-type bladeDimensions, Length x Width x Height, mm8478 x 4314 x 3970 (with ripper)Weight, kg48,888 (with ripper)Blade dimensions, Width x Height, mm4314 x 1765Max. drop below ground, mm614Dozing capacity, m³13.5RipperType1-shankRipper's weight, kg4300Rippering angle, °45
