| Blade type | Tilting blade |
| Operation weight(kg) | 24840 |
| Ground pressure(kpa) | 76 |
| Tracks gauge(mm) | 2000 |
| Scopr capacity | 30°/25° |
| Min. Ground clearance(mm) | 405 |
| Blade capacity(m³) | 7.8 |
| Blade width (mm) | 3666 |
| Max. Cutting depth(mm) | 540 |
| Overall demension (l*w*h) mm | 5733*3666*3380 |
| Engine |
| Model | NT855-C280 |
| Rated revolution(rpm) | 2000 |
| Rated power(kw) | 185/2000 |
| Max. Torque(n.m/rpm)- | 1050/1400 |
| Fuel consumption(g/kw.h) | 217 |
| Implement hydraulic system |
| Max. System pressure(mpa) | 19.1 |
| Oil pump type | Gear oil pump |
| system flow(l/min) | 194 |
| Undercarriage system |
| Type | Semi-rigid structure, swing type with equalizer bar |
| Numers of the track roller (each side) | 7 |
| Numbers of carrier roller (each side) | 2 |
| Pitch of links(mm) | 216 |
| Width of track shoe(mm) | 560 |
| Travel speed |
| | Gear 1 | Gear 2 | Gear 3 |
| Forward | 0-3.8 | 0-6.8 | 0-11.8 |
| Reverse | 0-4.9 | 0-8.5 | 0-14.3 |
| Power trasfer system |
| Torque convertor | Single stage, single phase, 3 elements |
| Transmission | :planetary gear transfer, power shift transmission,. 3 forward and 3 reverse, |
| Steering clutch | Oil type, multi metal discs with powder, spring pressed, hydrauliclly separated |
| Brakes | Oil type, floated, two direction belts, pedal mechanic operated |
Final drive
| Double stage reduction with gears, with floated seal ring, combined sprocked segments. |
