Chinese Brand Oriemac Xe135b 13ton Excavators for Sale
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Type：Crawler Excavator
- Usage：Mining Excavator
- Bucket：Shovel
- Transmission：Hydraulic Transmission
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.1~0.5m³
Base Info
- Model NO.：Xe135b
- Size：Small-Scale
- Certification：CE, ISO9001: 2000
- Condition：New
- Transport Package：Nude Package, Suitable for Shipment
- Trademark：Oriemac
- Origin：Jiangsu
- HS Code：87059091
- Production Capacity：1000
Description
Model
Operating weight
Kg
13000
Bucket capacity
M³
0.4~0.52
Engine
Engine model
/
ISUZU BB-4BG1TRP
Direct injection
/
√
4x strokes
/
√
Water cooling
/
√
Turbocharging
/
√
Cylinders
/
4
Output power of engine
KW/rpm
72.7/2200
Max torque/speed
N.m/rpm
337.6/1600
Displacement
L
4.329
Main
performance
Travel speed
Km/h
5.16/3.03
Slewing speed
r/min
12.3
Gradient capability
°
≤35°
Ground pressure
KPa
40
Digging capacity of bucket
KN
85
Digging capacity of bucket rod
KN
65
Max traction force
KN
134
Hydraulic
system
Main pump
/
Two plunger pumps
Rated flow of main pump
L/min
2x123
Pressure of main sadety valve
MPa
31.4/34.3
Pressure of traveling system
MPa
34.3
Pressure of swing system
MPa
25
Pressure of pilot system
MPa
3.9
Oil volume
Fuel tank capacity
L
250
Hydraulic tank capacity
L
130
Engine oil volume
L
14
