• Model NO.：970E
• Size：Large-Scale
• Certification：CE
• Condition：New
• Operating Weight with Cab：70500-70960 Kg
• Engine Model：Cum-Mins Qsx15
• Engine Power：373 Kw,500 HP
• Cutting Height：10950 mm
• Digging Reach：11450 mm
• Digging Depth：7180 mm
• Dumping Height：7030 mm
• Specification：12230*4260*4710 mm
• Origin：China
• HS Code：8429521100
• Production Capacity：1000,PCS

Basic Info.

Model NO. 970E Size Large-Scale Certification CE Condition New Operating Weight with Cab 70500-70960 Kg Engine Model Cum-Mins Qsx15 Engine Power 373 Kw/500 HP Cutting Height 10950 mm Digging Reach 11450 mm Digging Depth 7180 mm Dumping Height 7030 mm Specification 12230*4260*4710 mm Origin China HS Code 8429521100 Production Capacity 1000/PCS

Product Description

Chinese Liugong Excavators 970e Heavy Large 70 Ton Crawler Excavators

1. The 970E is powered by the latest Cu-mmins QSX15 engine with a rated net power of 357 kW (479 hp) @ 1800 rpm in compliance with EU Stage IIIA emission standards.
2. Heavy duty undercarriage components, reinforced idler frame and optional full track guard guarantee the integrity of our undercarriage.
ROPS (Roll Over Protection System) and FOPS (Falling Object Protection System) safeguard your operator in the toughest environment.
3. Visibility is key to protecting your operator and workers on site. The large glass surface area, spacious cab, combined with the rear-view camera, provides an extraordinary view of the 970E's surroundings.

Performance Parameters


Model	970E
Operating weight with cab	70500-70960 kg
Engine model	Cum-mins QSX15
Engine power	373 kW/500 hp
Bucket capacity	4.0/4.3 m3
Maximum swing speed	6.8 rpm
Cutting height	10950 mm
Digging reach	11450 mm
Digging depth	7180 mm
Dumping height	7030 mm
Dimension	12230*4260*4710 mm
