• Model NO.：950e
• Size：Large-Scale
• Certification：CE
• Condition：New
• Operating Weight with Cab：46500-48300 Kg
• Engine Model：Cum-Mins Qsm11
• Engine Power：280 Kw,375 HP
• Cutting Height：9977 , 10618 mm
• Digging Reach：10625 , 11585 mm
• Digging Depth：6521 , 7380 mm
• Dumping Height：7038 , 7578 mm
• Specification：11515,12030*3340*3810 mm
• Origin：China
• HS Code：8429521100
• Production Capacity：1000,PCS

Basic Info.

Model NO. 950e Size Large-Scale Certification CE Condition New Operating Weight with Cab 46500-48300 Kg Engine Model Cum-Mins Qsm11 Engine Power 280 Kw/375 HP Cutting Height 9977 / 10618 mm Digging Reach 10625 / 11585 mm Digging Depth 6521 / 7380 mm Dumping Height 7038 / 7578 mm Specification 11515/12030*3340*3810 mm Origin China HS Code 8429521100 Production Capacity 1000/PCS

Product Description

Liugong 950e 50t Hydraulic Crawler Excavators

1. The 950E is powered by the latest Cu-mmins QSM11 engine with a rated net power of 260 kW (349 hp) @ 2,100 rpm in compliance with EU Stage IIIA emission standards.
2. Heavy duty undercarriage components, reinforced idler frame and optional full track guard guarantee the integrity of our undercarriage.
ROPS (Roll Over Protection System) and FOPS (Falling Object Protection System) safeguard your operator in the toughest environment.
3. Visibility is key to protecting your operator and workers on site. The large glass surface area, spacious cab, combined with the rear-view camera, provides an extraordinary view of the 950E's surroundings.
Inspection parts, filters and water separator are conveniently located.

Performance Parameters


Model	950E
Operating weight with cab	46500-48300 kg
Engine model	Cum-mins QSM11
Engine power	280 kW/375 hp
Bucket capacity	2.2 / 2.6 / 2.8 / 3.2 m3
Maximum swing speed	8.5 rpm
Cutting height	9977 / 10618 mm
Digging reach	10625 / 11585 mm
Digging depth	6521 / 7380 mm
Dumping height	7038 / 7578 mm
Dimension	11515/12030*3340*3810 mm
