7.5t Wheel Excavator 360 Degree Rotation Mini Excavator for Sale
JINING OKING TEC CO., LTD.- Type：Wheel Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket：Backhoe
- Transmission：Hydraulic Transmission
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.1~0.5m³
Base Info
- Model NO.：OKW-7.5T
- Size：Medium-Sized
- Certification：CE, ISO9001: 2000
- Condition：Used
- Operating Weight：7500
- Boom Length：3250
- Arm Length：1850
- Counterweight Ground Clearance：929
- Tail Swing Radius：1904
- Min Ground Clearance：220
- Wheel-Base：1670
- Max Digging Distance：6203
- Max Digging Depth：3633
- Max Digging Height：6832
- Engine Model：A498bzg-9
- Bore*Stroke：95,105
- Rated Speed：2400
- Rated Power：55
- Engine Weight：320
- Transport Package：Export Packing
- Specification：7500kg
- Trademark：OUKE
- Origin：Jining
- HS Code：8429521200
- Production Capacity：200
Description
Item
data
BASIC
PARAMETERS
operating weight
6700kg
volume of bucket
0.28m3
overall length
6000mm
overall width
2150mm
upper structure width
2000mm
overall height
2729mm
boom length
3250mm
arm length
1850mm
ground clear ance
929mm
rear-end swing radius
1904mm
Min.ground clearance
220mm
tyre gauge
1670mm
wheel shaft diameter
2400mm
OPERATING
SCOPE
Max.digging reach
6203mm
Max.digging depth
3633mm
Max.digging height
6832mm
Min.swing radius
2138mm
PERFORMANCE
PARAMETERS
power system
engine model
YD4JZG
modality
Water cooling / hydraulic
power
55/2400kw/rpm
Max.torque
245/1610N.m/rpm
hydraulic ayatem
hydraulic pump
SGP1A2XF2H9
hydraulic pump
T5VP2D27
value
Parker
hydraulic oil tank
110L
fuel tank
130L
operating system
swing speed
12rpm
travel speed
35km/h
bucket digging force
44kn
arm digging force
35kn
Max.hauling force
65kn
gradeability
35°
parking brake
Air break
ervice brake
Air brake
Product Details
FAQ
Q: Are u the manufacturer ?
A: Yes, we are factory.
Q: What's your MOQ of this term?
A: 1 set.
Q: How long is your warranty?
A: Guarantee for 12 mounths starting from products arriving the destination port.
Q: Could you stick customers brand on the products?
A: Of course, we welcome the OEM orders.
Q: What's your delivery time?
A: Delivery timely about 7 days after receiving the deposit.
