• Model NO.：XS183
• Travel Speed：30cm,s
• Centrifugal Force：30.5KN
• Certification：ISO 9001:2008
• Condition：New
• Operating Weight：18000kg
• Load Applied on Front Drum：11500kg
• Static Linear Pressure：529n,Cm
• Theoretical Gradeability：50%
• Min. External Turning Radius：6500mm
• Compacting Width：2130mm
• Vibration Frequency(Low/High)：28,33Hz
• Exiting Force(High/Low)：340,240kn
• 2017：18ton Roller
• XCMG：Single Drum Roller
• Transport Package：Comply with Export Packaging Requirements
• Specification：ISO
• Trademark：XCMG
• Origin：Jiangsu, China
• HS Code：84294019
• Production Capacity：10000 Unit,Units , Year

TypeUnitXS183Operating weightkg18000Load applied on front drumkg11500Load applied on rear wheelskg6500Compacting widthmm2130Static linear loadN/cm529Vibration frequency(Low/High)Hz28/33Nominal amplitude(High/Low)mm1.86/0.93Exiting force(High/Low)KN340/240Travel speedkm/h0~10Steering angle°±33Swing angle°±10Theoretical  gradeability%50Min. external turning radiusmm6500Engine model DEUTZ BF6M2012CEngine powerkw136Rated engine speedr/min2200Engine oil consumptiong/kW.h222Hydraulic oil tank capacityL240Fuel tank capacityL240
 [Company Information]



Company profile
XCMG is a construction machinery manufacturer with over 70 years of experience. Over the years, we have grown to become the world's most comprehensive construction machinery manufacturer and influential multinational company. In 2015, we rank No.1 in China and No. 5 in global heavy equipment industry.XCMG's construction machinery covers an astonishing range of equipment, including cranes, earth-moving  machinery, road machinery, excavators, concrete machinery, mining machinery, piling machinery, lumber machinery, fire-fighting machinery, heavy trucks, sanitation machinery, agricultural machinery, and more. We have the world's most comprehensive product line, and offer customers complete solutions for construction equipment.  Our other businesses include finance, leasing, and remanufacturing.

At present, the power of my company's straight-arm crane is entirely from the hydraulic oil pressure, that is, through the high-pressure hydraulic oil to promote the cylinder piston reciprocating motion, or drive the hydraulic motor rotation makes the hydraulic winch and rotary mechanism rotation.

So, how do high-pressure hydraulic oil get? Each truck crane is equipped with a hydraulic pump when the vehicle chassis is matched, and the engine provides power for it. The chemical energy of the fuel can be converted into the crankshaft of the engine to rotate the mechanical energy, and then the gearbox gear is rotated, and then the power is transmitted to the hydraulic pump through the power transmission of the gearbox. Therefore, the hydraulic pump can continuously pressurize the hydraulic oil For the high-pressure hydraulic oil, so as to provide power for the crane to achieve the lifting of the goods.

Competitive Advantage
My company's straight arm crane crane covers 1-25 tons 14 models 65 kinds of products, to meet a variety of conditions, with the longest arm of the largest tonnage crane mature manufacturing technology, scientific research and development process, advanced Research and development technology, and constantly have new products to market, to meet customer use.
My company's boom arm section with mature pentagonal, hexagonal and octagonal, the latest generation of products with U-shaped arc arm body weight reduction, arm width of a large deflection, stability and resistance to deformation Ability to improve, significantly enhance the lifting capacity.
The application of the sub-arm, sub-winch and vice-hook provides a basis for the rapid and large-scale operation of the crane light load and the high-altitude operation. The application of automatic hook technology saves time and effort when starting and ending crane operations, making it easy to operate easily.
