- Model NO.:CLW5100GLQ3
- Certification:ISO9001: 2000, CE
- Condition:New
- Tank Capacity(M3; ):4.6
- Asphlt Bump:High Viscosity Asphalt Bump
- Hydraulic System:Shangxi Yuci Brand
- Controlling Meathod:Intelligent Control
- Heating Meathod:Automatic Heating
- Burner Brand:Italy Brand G20
- Spraying Width(M):6
- Spraying Volume(L/M3):0.3-3
- Transport Package:Naked, RO-RO, Bulk. Container
- Specification:CCC, ISO9001, ISO14001
- Trademark:CLW
- Origin:Hubei Suizhou
- HS Code:870510910
- Production Capacity:100units,Month
Dongfeng 5cbm Asphalt Distributor Truck |
Main parameter | Model No. | CLW5100GLQ3 | Emission Standard | |
G.V.W(Kg) | 9750 | Overall dimension (mm) | 7080X2300X2650 |
Curb weight(Kg) | 5600 | Rated weight(Kg) | 3955 |
Axles Load(Kg) | 3400/6350 | Cabin | 3 passengers allowed |
Chassis parameter | Chassis model | EQ1110T9ADJ3AC | Tire | 8.25-16,8.25R16,7.50-16,7.50R16 |
Approach/departure angle (°) | 22/10 | Front/rear Tread(mm) | 1831,1750/1640,1586 |
Wheelbase(mm) | 3800 | Front/rear suspension (mm) | 1180/2100 |
Leaf of springs | 11/9+7,8/10+7 | Minimum Ground Clearance (mm) | |
Engine | Engine model | ISDe140 30 | Manufacturer | Dongfeng |
Max. Power(Kw) | 103 | Displacement(ML) | 4500 |
Emission standard | GB3847-2005,GB17691-200 Euro III | Fuel | Diesel |
Spray Specification | Tank Capacity(m ³ ) | 4.6 | Spray width(mm) | 6000 |
Materials | Q235A carbon steel | Spray Value(Kg) | 0.5-3.0 |
Tank Size(mm) | 3100/1700/1300 | Insulation Thickness(mm) | 50 |
Chengli Special Automobile Co., Ltd, as the "Alibaba Group" in the special vehicle circle, has developed into the biggest professional special vehicle manufacturer of central China starting from scratch since 2004.LPG tank is one of our most advantageous key products which ranks Top 5 in China, excellent engineers and high-grade production equipment as well as strict quality control system can ensure all the tank work well with 10-20 years use life. About our "Chengli Special Automobile co.,Ltd":3000 Acres(2 million SQM) Factory 8000 Workers with Professional Training 300 Different Types of Trucks Available for Choice300 Million Total Sales Volume for 2014More Than 10 Years Manufacturing Experience Our main products: 1. Dump Truck / Tipper Truck/Side Tipper/End Tipper2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine3. Truck with crane / Truck mounted crane4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck5. Water truck / Water Tank Truck / Water Sprinkler Truck6. Concrete Mixer Truck7. Van truck / Insulated truck/ Refrigeration truck8. Fecal suction truck / Sewage suction truck, 9. Cement Powder Tank truck/ Bulk cement truck10. High-altitude operation truck, 11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck, 12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. ) Each customer who buy our ChengLi products can enjoy below benifits: 1. 3rd party inspection, such as BV, Intertek, etc before sale. 2. Spare Parts guarantee : 1. Supplying quick-wearing parts at the truck delivery. 2. Good quality parts produced by the truck manufacturing factory. 3. Only charge cost price for customer convenience. 3. Free warranty for 3 main components :Enginee, Gearbox, Axles. 4. After Sales Service : Email & Phone call tracking for each truck on timely manners, also possible engineer maintenace in customer's Country.
