• Model NO.：L68-C3
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Large Loader
• Transport Package：Nude Pacakge
• Specification：21.5 ton
• Trademark：SINOMADA
• Origin：China
• HS Code：8429521200
• Production Capacity：50000pieces,Year

Basic Info.

Model NO. L68-C3 Load and Unload Mode Front Discharge Walking Mode Wheeled Type Large Loader Transport Package Nude Pacakge Specification 21.5 ton Trademark SINOMADA Origin China HS Code 8429521200 Production Capacity 50000pieces/Year

Product Description

SHANTUI L68-C3 Articulated Wheel Loader Telescopic Boom LoaderPower System

Weichai electronically controlled engine conforms to the China-III non-road machinery emission regulation, featuring high intelligence and efficiency, high parts interchangeability, and low maintenance cost.
The machine is provided with three power modes, namely no-load, medium-load, and heavy-load modes, at choice depending on the actual working load to realize the reasonable match among power, efficiency, and energy consumption.

Drive system

The Hangzhou Advance 6t special planetary transmission + torque converter or ZF200 transmission + torque converter is applied to realize more reasonable match and faster response.

The KD gear, 1st gear, and 2nd gear of the electronic control transmission are shifted automatically to ensure simple and flexible operations.

Parameter name	L68-C3 HD (Heavy-duty version)	L68-C3 CH (Coal version)	L68-C3 MH (Ore version)
Performance parameters
Operating weight (Kg)	21500	20900	21960
Maximum dumping height (mm)	3325 (Standard boom)3450 (Extended boom)	3755 (Long Boom)	3288
Dumping reach (mm)	1270 (Standard boom)1275 (Extended boom)	1266 (Long Boom)	1281
Maximum breakout force (kN)	180	180	180
Total cycle time (s)	11.3	11.3	11.3
Engine
Engine model	WP10	WP10	WP10
Rated power/rated speed (kW/rpm)	178/2200	178/2200	178/2200
Overall dimensions
Overall dimensions of machine (mm)	8670*3072*3640	8725 (Extended boom)/9055 (Long Boom)*3050*3050	8890*3072*3640
