Shantui 23 Ton Excavator Se220LC with 112kw Engine Power
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Crawler Excavator
- Usage：GM Excavator
- Bucket：Backhoe
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：SE220LC
- Drive Type：Electric Drive
- Bucket Capacity：1.05cbm
- Certification：CE, ISO9001: 2000
- Condition：New
- Tail Turning Radius (mm)：2925
- Track Length (mm)：4460
- Track Gauge (mm)：2380
- Track Width (mm)：3180
- Standard Track Shoe Width (mm)：800
- Turntable Width (mm)：2725
- Maximum Digging Height (mm)：10075
- Maximum Dumping Height (mm)：7165
- Maximum Digging Depth (mm)：8515
- Maximum Vertical Digging Depth (mm)：5795
- Maximum Digging Distance (mm)：9865
- Engine Model：B5.9-C
- Rated Power (Kw/Rpm)：112,1950
- Maximum Swing Speed (R/Min)：10.2
- Bucket Arm Digging Force (Kn)：92.5
- Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Containe
- Specification：5025*3035*3180mm
- Trademark：shantui
- Origin：China
- Production Capacity：300piece,Month
Description
Basic Info.
Model NO. SE220LC Drive Type Electric Drive Bucket Capacity 1.05cbm Certification CE, ISO9001: 2000 Condition New Tail Turning Radius (mm) 2925 Track Length (mm) 4460 Track Gauge (mm) 2380 Track Width (mm) 3180 Standard Track Shoe Width (mm) 800 Turntable Width (mm) 2725 Maximum Digging Height (mm) 10075 Maximum Dumping Height (mm) 7165 Maximum Digging Depth (mm) 8515 Maximum Vertical Digging Depth (mm) 5795 Maximum Digging Distance (mm) 9865 Engine Model B5.9-C Rated Power (Kw/Rpm) 112/1950 Maximum Swing Speed (R/Min) 10.2 Bucket Arm Digging Force (Kn) 92.5 Transport Package Nude Package/RO-RO/Bulk Shipment/Suitable Containe Specification 5025*3035*3180mm Trademark shantui Origin China Production Capacity 300piece/MonthProduct Description
Shantui 23 Ton Excavator SE220LC With112Kw Engine Power____________________________________________________________________
CHARACTERISTICHigh-end system configuration
Cummins B5.9 six-cylinder engine, national II emission standard, strong power, durable, equipped with a three-level fuel filter system, escort.
Optimal negative flow control hydraulic system, reliable performance, easy to maintain;
Large displacement main pump and engine perfect match, the whole machine speed is faster.
Durable structural parts1. Standard reinforced bucket
2. Front support casting form, strengthened sticking plate in key parts, better reliability.
3. The front fork and backseat of the movable arm adopt the casting box body, and bear the load of multi-directional variable torque.
4. X-shaped box structure of lower frame, strong bearing capacity, thickened plate in key parts, reliable and durable.
Durable structural parts1. Standard reinforced bucket
2. Front support casting form, strengthened sticking plate in key parts, better reliability.
3. The front fork and backseat of the movable arm adopt the casting box body, and bear the load of multi-directional variable torque.
4. X-shaped box structure of lower frame, strong bearing capacity, thickened plate in key parts, reliable and durable.
Intelligent electronic control and optimal power controlFuel filling pump
Cab alarm light
Bridge overhead light
Anticollision beam
Bridge roof protection net
Safety net in front of cab
Front and lower bridge safety net
Rubber tracks
Machine optional configurationFuel filling pump
Cab alarm light
Bridge overhead light
Anticollision beam
Bridge roof protection net
Safety net in front of cab
Front and lower bridge safety net
Rubber tracks
Optional accessory deviceFuel filling pump
Cab alarm light
Bridge overhead light
Anticollision beam
Bridge roof protection net
Safety net in front of cab
Front and lower bridge safety net
Rubber tracks
PARAMETER| Comparative item | SE220LC |
| Overall dimensions | |
| Overall length (mm) | 9615 |
| Ground length (During transport) (mm) | 5025 |
| Overall height (To the top of boom) (mm) | 3035 |
| Overall width (mm) | 3180 |
| Overall height (To top of cab) (mm) | 3045 |
| Ground clearance of counterweight (mm) | 1055 |
| Minimum ground clearance (mm) | 466 |
| Tail turning radius (mm) | 2925 |
| Track length (mm) | 4460 |
| Track gauge (mm) | 2380 |
| Track width (mm) | 3180 |
| Standard track shoe width (mm) | 800 |
| Turntable width (mm) | 2725 |
| Distance from slewing center to tail (mm) | 2920 |
| Working range | |
| Maximum digging height (mm) | 10075 |
| Maximum dumping height (mm) | 7165 |
| Maximum digging depth (mm) | 6515 |
| Maximum vertical digging depth (mm) | 5795 |
| Maximum digging distance (mm) | 9865 |
| Maximum digging distance at ground level (mm) | 9685 |
| Working device minimum turning radius (mm) | 2970 |
| Engine | |
| Model | Cummins B5.9-C |
| Type | Water cooled, six cylinder in-line, turbocharged |
| Displacement (L) | 5.9 |
| Rated power (kW/rpm) | 112/1950 |
| Hydraulic system | |
| Type of hydraulic pump | Variable piston pump |
| Rated working flow (L/min) | 2x218 |
| Bucket | |
| Bucket capacity (m³) | 1.05 |
| Swing system | |
| Maximum swing speed (r/min) | 10.2 |
| Brake type | |
| Digging force | |
| Bucket arm digging force (KN) | 92.5 |
| Bucket digging force (KN) | 127 |
| Operating weight and ground pressure | |
| Operating weight (kg) | 22800 |
| Ground pressure (kPa) | 35.3 |
| Traveling system | |
| Traveling motor | Axial variable plunger motor |
| Traveling speed (km/h) | 3.2/4.7 |
| Traction force (KN) | 203 |
| Gradeability | 70% |
| Tank capacity | |
| Fuel tank capacity (L) | 330 |
| Cooling system (L) | 28 |
| Engine oil capacity (L) | 20 |
| Hydraulic oil tank/system capacity (L) | 400 |
