• Model NO.：Liugong 24m Concrete Pump Truck
• Vibrating Amplitude：2.2mm
• Certification：ISO9001: 2000
• Condition：New
• Color：White
• Chassis：Sinotruk
• Engine Power：213kw
• Pump Length：24m
• Payment Term：Tt or LC
• Delivery Time：10-30 Days
• Transport Package：Suitable Package for Shipment
• Specification：Standard Configuration
• Trademark：Liugong
• Origin：Jiangsu, China
• HS Code：84294019
• Production Capacity：20 Sets, Month

Basic Info.

Model NO. Liugong 24m Concrete Pump Truck Vibrating Amplitude 2.2mm Certification ISO9001: 2000 Condition New Color White Chassis Sinotruk Engine Power 213kw Pump Length 24m Payment Term Tt or LC Delivery Time 10-30 Days Transport Package Suitable Package for Shipment Specification Standard Configuration Trademark Liugong Origin Jiangsu, China HS Code 84294019 Production Capacity 20 Sets/ Month

Product Description

Chassis ModelSINOTRUF ZZ1161M5011C
Emission Stage Euro III or Euro IV
Engine rated Power213 kW @ 2, 200 rpm
Concrete Output110/65 m3/h
Concrete Pressure7/12 MPa
Max. Vertical Reach23.1 m
Main Hydraulic Pump Displacement190 ml/r
Concrete Slump120-230 mm
The imported engine with original packing has strong power, and can meet the requirements of high-efficient work.
- Precise matching design with advanced energy conservation control can reduce the oil consumption of the machine.
- Low emission meets the Europe II standard.
- The adoption of new cooling fan and large-scale silencer lowers the noise of the machine.
- The adoption of the advanced turbocharging technique increases the highland adaptability of the machine.
- Automatic preheating system improves the working capacity in the low temperature.
- Unique fan cover with the shape of hopper opening greatly improves the air supply of the engine and the radiating capacity of the system, guaranteeing the successive high-efficient work of the machine.
- Restart prevention system effectively avoids the misoperation, and improve the use security of the machine.

========================================================================
