• Model NO.：RE10
• Drive Type：Internal Combustion Drive
• Bucket Capacity：0.035
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Transport Package：Container or Wooden Case Package
• Specification：2, 550*930*1, 550
• Origin：China
• HS Code：84295212
• Production Capacity：2, 000,Year

Basic Info.

Model NO. RE10 Drive Type Internal Combustion Drive Bucket Capacity 0.035 Size Small-Scale Certification CE, ISO9001: 2000 Condition New Transport Package Container or Wooden Case Package Specification 2, 550*930*1, 550 Origin China HS Code 84295212 Production Capacity 2, 000/Year

Product Description

This type of excavators are mainly applied to: farming, landscaping, ditching and fertilization in garden, vegetable greenhouse, agricultural transformation, indoor demolition, small earthwork, civil engineering, road recovery, basement and indoor construction, concrete breaking, burying of cable, laying of water supply line, garden cultivation, desilting and others.

The excavator are equipped with Changchai/Ligong EURO 5 diesel engines, well-known main pump and rotary motor and traveling motor, featuring comprehensive guarantee, durability and flexibility.

Features:

• Small and flexible, easy operate for narrow places.
• Parts are made out of stainless steel or spraying plastics technology for lasting longer service life.
• 360°rotation, easy learning and operating.
• Light weight and transport easily with good performance.

Specifications:

Model	RE10
Operating Weight	980kg
Bucket Capacity	0.035m³
Bucket Width	420mm
Boom Length	1,350mm
Arm Length	700mm
Travel Speed	0-3.5km/h
Grade Ability	35%
Ground Pressure	25Kpa
Bucket Digging Force	800kg
Arm Digging Force	600kg
Engine Brand	Changchai 192F
Rated Power	12/9/2/2,200 (p/kw/rpm)
Displacement	0.499
Cylinders	1
Cooling Type	Air-Cooling
Main Pump	306
Rated Pressure	18Mpa
Main Pump Max. Flow	6L/min
Hydraulic Motor	Factory Made
Swing Hydraulic Motor	BM2
Fuel Tank	12L
Hydraulic Oil Tank	18L
Hydraulic System	Gear Pump
Engine Oil	2.5L
Fuel Consumption	0.8-1.2L/h
Overall Dimensions	2,550*930*1,550mm
Superstructure Width	930mm
Counterweight Ground Clearance	400mm
Total Track Length	1,200mm
Track Shoe Width	180mm
Total Track Width	930mm
Min. Front Swing Radius	1,800mm
Doze Blade Width	930mm
Max. Digging Radius	2,550mm
Max. Digging Depth	1,600mm
Max. Digging Height	2,500mm
Max. Dumping Height	1,750mm
Dozer Blade Width	930*210mm

About Us:
RIGID INDUSTRIES CO., LTD is a company who has over 10 years experience in construction machinery industry. We started doing machinery export in 2008. We are located in Dalian, which is a very well-known coastal and harbour city in China.

In machinery industry, We have very much learned about the strengths and weaknesses from different types of Chinese construction machines such as wheel loaders, excavators, skid loaders, forklifts, backhoe loaders, graders as well as related attachments etc. We know the differences of standards and requirements from different markets. Now our products can be found that working and serving in more than 20 countries in the world.

Products' research&development is always the most important factor in RIGID's success and we are specializing in manufacturing and exporting. RIGID INDUSTRIES knows the international standards and requirements of machines, and most of our products have also passed CE, SGS, TUV certificates. Also, our target markets are mainly focus on developed countries such as Australia, New Zealand, North America and Europe.

Moreover, providing excellent after sale services is another significant factor to lead our business successfully and also it is always our first principle in RIGID's culture. We will help our customers to buy and store spare parts in local and also we will ship parts for free for our customers if necessary when some parts are broken during the warranty.

We hope our professional experiences and skills could make our customers' businesses great, prosperous and long last. We look forward to establishing long-term cooperations with our customers in the future.

FAQ:
Q1. What is the leading time of RE10 mini excavator?
The leading time is about 10 days.

Q2. What is the payment term will you accept?
30% deposit, 70%TT balance payment before the shipping..

Q3. What is the warranty for the RE10 mini excavator?
12 months for a whole machine, 6 months for hydraulic parts.

Q4. What is the MOQ for RE10 excavator?
MOQ: 1 unit

Q5. What after sale services can you provide?
We can ship some urgent parts to our customers for free through DHL or TNT if they are during the warranty.
They generally take 5-7 working days to our customers' hands.
If some parts are too big or too heavy, we will ship them with machines in the next order for free.

Q6. Can you do OEM for overseas dealers?
Yes, we also can do paint customization for our dealers, but it is only for a 40ft container's order.


We also can provide other types of machines such as forklifts, graders, backhoe loaders, rollers, bulldozers, dumpers, trailers, tractors and related attachments.

If you have any questions that I can answer or need anything of our machines, we are very happy to do so.
