• Model NO.：43X-5RZ
• Productivity：240m²,h
• Feeding Height：1400mm
• Vibrating Amplitude：2.6mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：White
• Stroke Length：1700 mm
• Filling Height：1540 mm
• Pumping Frequency：24,15min-1
• Hopper Capacity：550L
• Transport Package：Nude
• Specification：10740x2500x3886 mm
• Trademark：ZOOMLION
• Origin：China
• HS Code：87059090
• Production Capacity：100 Units, Month

Overview Product Description



• Compact in design, 43m pump mounted on a 4-axle truck.
• Efficient pump unit, ideal for long time use.
• Agile placing boom with 5 arms with unfolding height 9.1m only, which gives a wide work range.
• One side lateral support enables to work in narrow sites.
• Controller is designed for heavy duty use, with a monitor which monitors the pump intelligently on working data management, real-time diagnostics, alarm logging, and service interval notice.
• Various configurations and high quality components.
• Damping technology boom.
• Boom stabilization control.
• Multilingual man-machine interface system.
• PWM+CAN dual communication mode remote control.

Product Parameters



ModelUnit43X-5RZPump UnitMax. Theor. output                       m³/h140/90Max. Theor. concrete output Pressure     MPa7/11Rated working pressure                      MPa35Pumping frequency                             min-127/17Hopper    capacity                    L550Filling height                                  mm1540Hydraulic system type opened loopDistribution valve S valveOil cylinder dia.×stroke                   mmφ130×2100Concrete cylinder    dia.×stroke            mmφ230×2100Hydraulic oil cooling Wind coolingRecommended concrete slump                   cm12~23Max. aggregate dimension                    mm40Boom    SectionStructure type 43X-5RZPlacing depth                               m43Max. horizontal distance                     m39Max. placing depth                          m30.46Slewing angle ±270°Boom number 5The length of boom section                       mm8350/7250/7050/7930/8420Sections folding angle 90°/180°/180°/240°/200°Pipe diameter                               mm125End hose lengthmm3000Min. height of opening placing boom       mm9100Outriggers span     (front×rear×side)  mm8220×8800×8900Detailed Photos
