135HP with High Efficiency Motor Grader Gr135 with High Efficiency

Sinomada Heavy Industry (Changsha) Co., Ltd.
  • After-sales Service：Free Spare Parts
  • Warranty：1 Year
  • Certification：TUV, UL, ISO, RoHS, CE
  • Condition：New
  • Application：Railway, Mine, Farmland, Highway
  • Transmission：Hydraulic

Base Info

  • Model NO.：GR135
  • Walking Mode：Wheeled
  • Type：Oversize Grader
  • Total Weight (Standard)：11000kg
  • Rated Power/Speed：97(2200)Kw(R,Min)
  • Forward Velocity：5,8,13,20,30,42km,H
  • Reverse Speed：5,13,30km,H
  • Engine Model：6bt5.9-C130-2
  • Transport Package：Nude
  • Specification：8015*2380*3050mm
  • Trademark：XC MG
  • Origin：China
  • HS Code：8565656456
  • Production Capacity：100units,Month

Description

DescriptionUnitParameter valueEngine model  6BT5.9-C130-2Rated power/speed kw(r/min)97(2200)Overall dimension (standard)  8015X2380X3050Total weight (standard) kg11000Tire specification  13.00-24Ground clearance (front axle) mm515Tread mm2020Space of front and rear axles mm5780Forward velocity km/h5/8/13/20/30/42Reverse speed km/h5/13/30Tractive effort f=0.75 kN61.3Maximum gradeability %20Tire inflation pressure kPa300Working system pressure MPa16Transmission pressure MPa1.3-1.8Maximum steering angle of front wheel  ±49°Maximum slant angle of front wheel  ±17°Maximum oscillating angle of front axle  ±15°Maximum oscillating angle of equilibrium box  ±16°Maximum steering angle of frame  ±27°Minimum turning radius m6.6



Scrape knifeMaximum lift heightmm410Maximum cutting depthmm515Maximum tilt angle 90°Cutting angle 54°-90°Angle of revolution 360°Length & chord heightmm3048x610Coolant L50Fuel tank L260Engine L18Transmission L26Hydraulic oil L96Drive axle L28Balancing box L46
