800kg China Famous Brand Mini Excavator with Yanmar Engine
Wuhan Kudat Industry & Trade Co., Ltd.- After-sales Service：1 Years
- Warranty：1 Years
- Type：Crawler Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket：Shovel
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：KD08
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.1~0.5m³
- Size：Small-Scale
- Certification：CE, ISO9001: 2000
- Condition：New
- Color：Orange
- Engine Model：Yanmer 2tnv70
- Cylinders：2
- Bore/Stroke：70*74
- Displacement：0.569L
- Fuel：Diesel
- Cooling：Water-Cooling
- Maximum Torque：33n. M
- Operating Weight：820kg
- Ground Pressure：25kpa
- Transport Package：Bulk
- Specification：SGS CE
- Trademark：KUDAT
- Origin：China
- HS Code：8429521000
- Production Capacity：10000PCS,Year
Description
Pump #1 for left travel and house swing and arm functionPump #2 for right travel and boom function and bucket function Swing- Motor(1) Fixed displacement Speed 9.2rpm Brake Hydraulically released with dual cushion relief Tail swing radius 820mm Travel- Motor(2) Fixed displacement axial piston design Final drive Planetary gear reduction Travel Speed 2km/h HYDRAULIC CYLINDERS Boom cylinder (1) Bore diameter 50mm Rod diameter 25mm Stroke 320mm Arm cylinder (1) Bore diameter 50mm Rod diameter 25mm Stroke 310mm Bucket cylinder (1) Bore diameter 50mm Rod diameter 25mm Stroke 235mm ELECTRICAL Voltage 12V Alternator 10amp Batteries(1) 12V Heavy-duty SERVICE CAPACITIES Hydraulic tank Refill capacity 16L Total system 20L Engine w/filter change 1.5L Fuel 9.5L Radiator 2.5L OPERATING WEIGHT With 75kg operator, full fuel and standard equipment 820kg Ground pressure 25kpa
