4X1000W Mobile Lighting Tower 9m Mast Diesel Outdoor Light Tower
Fujian Robust Power Co., Ltd.- After-sales Service:Warranty Service
- Warranty:3 Years
- Engine:Kubota D1105-Bg
- Power Generation:8kw
- Power:4*1100W
- Bulb Type:Halogen
Base Info
- Model NO.:RPLT-6000
- Usage:Camping, Emergency Lighting,Mining
- Mast Height:9m
- Engine Speed:1500rpm,1800rpm
- IP Grade:IP54
- Lumen Output:4*67,200lm
- Transport Package:Plywood Pallet,Plwood Case,Cartons
- Specification:ISO9001: 2000, CE
- Trademark:Robust Power
- Origin:China
- HS Code:94054090
- Production Capacity:250set,Month
Description
MastMaximum extention of mast 9m Elevation Mechanical/Electric Raising/lowing mast Winch(Mechanical)/Button(Electric) Stages 3 Turning angle 358 degrees non-continuous Lamp Total power of lamps 4X1000W Type of lamp Metal halide lamp Light capacity 4× 88, 000 lumen Voltage 120, 220, 230, 240 Frequency 50Hz/60Hz Lifetime of lamp 5000 hours Working temperature ≤ 85º C Connection Protection index IP54 Light Coverage 5 to 7 acres Characteristics of the generator Model RD10K Generator set Prime power 50Hz 6.7kW 60Hz 8.4kW Standby power 50Hz 7.3kW 60Hz 9 kW Engine model Kubota D1105-BG Diesel Engine speed 50Hz 1500rpm / 60Hz 1800rpm Engine type 3 cylinder, in line, water-cooled Engine Aspiration Natural Alternator Type 4-pole, brushless Fuel tank capacity 100L Prime fuel consumption at 100% load 2.0L/h Working hours 50 Control system GU602A Digital control panel Power Outlets 2 Trailer Tow hitch Ring or ball hitch Stabilier Supports 5 × Manual Tire Size 52cm Anti-wind capacity > 10 Brakes Manual Packing Dimension & Weight Retracted Dimension 4400mm × 1350mm × 1930mm
