Construction Machinery 16t Single Drum Vibratory Road Roller (Xs162j)
Shandong Shanglong Economic and Trade Corporation Ltd.- Type：Road Roller
- Working Method：Vibration
- Axle：Biaxial Dual-Drum
- Power：115 Kw
- Dimension(L*W*H)：6220X2340X3200 Mm
- Weight：16000 Kg
Base Info
- Static Linear Load：362 N,Cm
- Drum Width：2130 Mm
- Warranty Period：Within 1 Year
- A/C：Optional
- Fuel Tank Capacity：240L
- Transport：by 40′hq
- Transport Package：Nude in Container
- Specification：Standard
- Origin：China
- HS Code：84294019
- Production Capacity：300 Sets , Month
Description
Main specification:
1. Machinery single drum vibratory roller;
2. Imported open gear pump and motor;
3. Without Air conditioner;
4. Shanghai Diesel Water-cooledengine 115kw EURO II;Working performance parameters Static linear load N/cm 362 Vibration frequency(L/H) Hz 28 Nominal amplitude(High/Low) mm 1.9/0.95 Excitation force(High/Low) Kn 290/145 Drum width mm 2130 Min ground clearance mm 400 Driving performance parameters Speed I Km/h 2.54 Speed II Km/h 4.97 Speed III Km/h 10.51 Theoretical grade ability % 30 Min. external turning radius mm 6500 Steering angle ° ±33 Oscillating angle ° ±11 Basic parameter Operating weight Kg 16000 Weight on rear wheel Kg 8300 Weight on front drum Kg 7700 Overall size (LxWxH) mm 6220x2340x3200 Engine Engine model SC8D156.2G2B1 Type Water cooled, pressurized Rated speed r/min 1800 Rated power Kw 115 Hydraulic oil tank capacity L 170 Fuel tank capacity L 240
1. Machinery single drum vibratory roller;
2. Imported open gear pump and motor;
3. Without Air conditioner;
4. Shanghai Diesel Water-cooledengine 115kw EURO II;
