Liugong 14 Ton Roller Roller 6114e with High Technology
Maxizm Construction Machinery (Qingdao) Co., Ltd.- After-sales Service：Free Sapre Parts Onlion Support
- Warranty：1 Year
- Type：Road Roller
- Working Method：Steel Wheel
- Axle：Biaxial Dual-Drum
- Grinding Wheel Type：Tire Grind
Base Info
- Model NO.：6114E
- Compaction Depth：35cm
- Engine Type：Diesel Engine
- Travel Speed：35cm,s
- Centrifugal Force：30.5KN
- Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
- Operating Mass：14000 Kg
- Mass on Vibrating Drum：7000 Kg
- Mass on Drive Axle：7000 Kg
- Front Drum Static Linear Load：322 N,Cm
- Model：Shangchai Sc4h140.2g2
- Emission Regulation：Stage II
- Rated Power：103 Kw (140 HP) @ 2000 Rpm
- Vibration Frequency：30 Hz
- Transport Package：Nude
- Specification：2725*1400*2740 mm
- Trademark：LIUGONG
- Origin：China
- HS Code：84295100
- Production Capacity：10000 Units,Month
Description
Drive
1st Maximum Speed,fwd(km/h)
4.5
2nd Maximum Speed,fwd(km/h)
6.1
3rd Maximum Speed,fwd(km/h)
6.7
4th Maximum Speed,fwd(km/h)
12
Theoretical Gradeability(%)
50
Min. Ground Clearance(mm)
490
Wheelbase(mm)
3000
Steering Angle(°)
±35
Swing angle(°)
±10
Min. Outside Turning Radius(mm)
6500
Tyre Type
23.1-26-12PR
Tyre Pressure(kPa)
200-220
Overall Length(mm)
6000
