China Supplier Hzm Compact/Articulated/Multifunctional with CE/Euro 5/Bagger Radlader Bucket/Fork/Attachments/Cab/Rops/Roll Bar 811 Mini Loader for Sales/Garden
Qingzhou Huizhong Machinery Co., Ltd.- Warranty：1 Year
- Certification：CE
- Condition：New
- Rated Load：<1t
- Transmission：Hydraulic - Mechanical
- Load and Unload Mode：Front Discharge
Base Info
- Model NO.：HZM 811
- Walking Mode：Wheeled
- Type：Small Loader
- Dimension(Long * Breadth * High)：4036*1446*2260mm
- Size：Mini
- After-Sales Service Provided：Overseas Service Center
- Engine：Changchai Zn390q Engine
- Place of Origin：Shandong
- Rated Speed：30
- Standard Tire：750-16
- Brand Name：Hzm
- Transport Package：Container
- Specification：CE EPA
- Trademark：HZM
- Origin：Shandong Weifang
- Production Capacity：5000pec,Year
Description
Basic Info.
Model NO. HZM 811 Walking Mode Wheeled Type Small Loader Dimension(Long * Breadth * High) 4036*1446*2260mm Size Mini After-Sales Service Provided Overseas Service Center Engine Changchai Zn390q Engine Place of Origin Shandong Rated Speed 30 Standard Tire 750-16 Brand Name Hzm Transport Package Container Specification CE EPA Trademark HZM Origin Shandong Weifang Production Capacity 5000pec/YearProduct Description
Standard configuration
Changchai ZN390, 25kw,(34HP), 3 cylinders, Joystick operation, 750-16 standard tires.(31x15.5-15 wider tires are more recommended) floating function, 4x4 drive, heater inside cabin, 220V engine preheat (European connection), enlarged cabin space, more comfortable when working. back sound, radio, USB, hand brake, extinguisher, window hammer.
| Basic Parameters | overall weight(kg) | 2500 |
| L×W×H(mm) | 4200×1450×2280MM | |
| rated bucket capacity(m3) | 0.25 | |
| Rated load(kg) | 800 | |
| dump height (mm) | 2200 | |
| Lifting height(mm) | 2650 | |
| Dump distance | 700mm | |
| Wheelbase | 2100mm | |
| Thread | 1405mm | |
| Total time | 11s | |
| Engine | Model | Chang Chai ZN390 |
| horsepower | 34(hp) | |
| Type | direct injection, horizontal, water-cooled, four stroke, 3 cylinders | |
| Rated power(KW) | 25KW | |
| Rated speed(r/min) | 2200 | |
| Tire | Standard tires | 750-16 |
| Optional tires | 31X15.5-15 | |
| Transmission | Standard | Full Hydraulic |
| Optional | Torque converter |
