• Model NO.：SD32
• Engine Power：147~515kw
• Certification：CE, ISO9001: 2000
• Condition：New
• Color：Yellow
• Operating Weight (Kg)：3200
• Center Distance of Track (mm)：2140
• Width of Track Shoes (mm)：560
• Ground Length(mm)：3150
• Fuel Tank (L)：640
• Blade Type：Semi-U Blade
• Digging Depth (mm)：560,630,560
• Ripper Type：Single Shank,3 Shanks
• Ripping Depth (mm)：695,666
• Rated Power/Rated Speed (Kw/Rpm)：257,2000,258,2000
• Transport Package：Nude
• Specification：8650*4130*3760mm
• Trademark：Top brand
• Origin：China
• HS Code：84291190
• Production Capacity：2000

Parameter nameSD32 (Standard version)Performance parameters Operating weight (Kg)40200Ground pressure (kPa)97.7Engine Engine modelWP12/QSNT-C345Rated power/rated speed (kW/rpm)257/2000,258/2000Overall dimensions Overall dimensions of machine (mm)8650*4130*3760Driving performance Forward speed (km/h)F1:0-3.6 F2:0-6.6 F3:0-11.5Reversing speed (km/h)R1:0-4.4 R2:0-7.8 R3:0-13.5Chassis System Center distance of track (mm)2140Width of track shoes (mm)560/610/660/710Ground length(mm)3150Tank capacity Fuel tank (L)640Working device Blade typeStraight tilting blade , Angle Blade and Semi-U bladeDigging depth (mm)560/630/560Ripper typeSingle-shank three-shankRipping depth (mm)1,250 (Single-shank) and 842 (Three-shank)Company Information
