Tunnel Boring Machine / Pipe Jacking Machine / Single Disc Cutter / Tbm Cutter / Rock Drilling Tools / Raise Boring Cutter / Double Disc Cutter Ring
Jiangsu Attacking-Rock Engineering Equipment Co., Ltd.- After-sales Service：Yes
- Type：Tbm and Boring Machine
- Application：Tunnel Boring Machine
- Certification：CE, ISO9001: 2000, RoHS
- Condition：New
- Color：According to Your Request
Base Info
- Sample：Available
- Material：Mold Steel, H13, DC53, Gsy, Gld
- Hardness Range：HRC56-66
- After Warranty Service：Video Technical Support, Online Support
- Video Outgoing-Inspection：Provided
- Size：13" ~ 18"
- Bearing Capacity：40 ~ 42 Tonne
- Diameter(mm)：330mm ~ 457mm
- ODM/OEM：Acceptable
- Transport Package：Plywood
- Specification：CUSTOMED
- Origin：China
- HS Code：8207199000
- Production Capacity：30000PCS,Year
Description
Material of cutter ring
H13, with hardness HRC56-59, ,C 0.47-0.52 Si 0.9-1.2 Mn 0.4-0.6 Cr 4.8-5.2 Mo 1.1-1.4 V 0.8-1.00 P 0.015 S 0.015 shrink fit with hub.
DC53,with hardness HRC60-63,C 0.9-1.1 Si 0.9-1.2 Mn 0.2-0.4 Cr 7.5-8.5 Mo 1.9-2.3 V 0.3-0.5 P 0.015 S 0.015.
GSY,with hardness HRC61-64,Ingredient confidentiality.
GLD,with hardness HRC62-66,C 0.68-0.78 Si 0.9-1.2 Mn 0.2-0.4 Cr 7.0-8.0 Mo 2.2-2.5 V 1.7-2.2 P 0.015 S 0.015.
Generally the cutter ring material in two types, totally abrasion-resistant steel and steel with tungsten carbide inserts. The cutting edge of roller disc cutter is desiged in different shape according to different hardness of rock.
According to the work condition, the cutter ring should features:
- High yield strength, to prevent deformation under high stress;
- High hardness, increase the abrasion resistance decrease the wear and tear; High impact ductility, prevent any fracture;
- High resistance to tempering, increase the heat endurance to guarantee the hardness under hot charging or rolling the rock;
- High processing property for hot working and cold workin
Q: Are you a manufacturer or trading company?
A: We are a specialized manufacturer.
Q: What are your main products?
A: Our products include stainless iron 1-4Cr13,cold work die steel Cr12, Cr12Mov, Cr12Mo1V, Cr12Mo1V1 ,die steel H13ESR, DC53
Q: How about your payment term?
A: T/T, L/C, Western Union, Paypal, 30% deposit in advance and rest before delivery.
Q: How about discount?
A: Price is based on products and order quantity.
Q: Do you accept sample order?
A: Yes sure, please contact us for details.
Q: How about your after-sales service?
A: As a manufacturer, we offer promote technology support for all problems and questions. Besides, we accept goods return or replace for quality problem.
Q: How does your company control the quality?
A: we have Quality first. In order to guarantee high quality for our products, we always makes a serious inspection for all products and raw materials in strict procedure.
