Mini Digger 3.0 Ton Excavator Tracked Excavator with Rotating Arm
Shandong TOROS Machinery Co., Ltd.- After-sales Service：Provide a Lifelong Online Problem Solution
- Warranty：12 Months Warranty Service
- Type：Crawler Excavator
- Usage：Mining Excavator, GM Excavator
- Bucket：Backhoe
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：TE30
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.1cbm
- Size：Small-Scale
- Certification：CE, ISO9001: 2000, Euro 5 & EPA Approved
- Condition：New
- Excavator Width：1350mm
- Chassis Ground Clearance：240mm
- Volume of Fuel Tank：20L
- Transport Length：4180mm
- Excavator Height：2200mm
- Turning Radius：1300mm
- Max.Digging Height：3900mm
- Max.Dumping Height：2600mm
- Max.Digging Depth：2500mm
- Max.Digging Radius：5486mm
- Max.Vertical Digging Depth：2300mm
- Engine：Changchai , Yanmar
- Engine Power：Engine Power
- Overall Dimension ( Lxwxh)：4180*1350*2200mm
- Weight：2700kg
- Transport Package：FCL and LCL
- Specification：4180*1350*2200mm
- Trademark：TOROS
- Origin：Shandong, China
- HS Code：8429521200
- Production Capacity：5000sets,Month
Description
TE30 Mini Crawler excavator METRIC IMPERIAL Bucket Capacity 0.1m³ Bucket Capacity 3.53ft³ Excavator Width 1350mm Excavator Width 53.15in Track Length 2000mm Track Length 78.74in Chassis Ground Clearance 240mm Chassis Ground Clearance 9.45in Track Width 230mm Track Width 9.06in Volume of fuel tank 20L Volume of fuel tank 4.4UK gal Gradeability 30° Gradeability 86ºF Transport Length 4180mm Transport Length 164.57in Excavator Height 2200mm Excavator Height 86.61in Overall Dimension ( LxWxH) 4180*1350*2200mm Overall Dimension ( LxWxH) 164.57*53.15*86.61in Multi-way Valve EATON Traveling Motor Multi-way Valve EATON Traveling Motor Engine CHANGCHAI / YANMAR Engine CHANGCHAI / YANMAR Engine Power 24.5kw/2200rpm 19.6KW/2300rpm Engine Power 32.86hp/2200rpm 26.28hp/2300rpm Turning Radius 1300mm Turning Radius 51.18in Max.Digging Height 3900mm Max.Digging Height 153.54in Max.Dumping Height 2600mm Max.Dumping Height 102.36in Max.Digging Depth 2500mm Max.Digging Depth 98.43in Max.Digging Radius 5486mm Max.Digging Radius 215.98in Max.Vertical Digging Depth 2300mm Max.Vertical Digging Depth 90.55in MAX.Digging Force 22KN MAX.Digging Force 22KN Weight 2700kg Weight 5952lb 7.70oz EATON Swing Motor Taifeng Plunger Hydraulic Pump EATON Swing Motor Taifeng Plunger Hydraulic Pump
