Factory Direct Sale Wall Cement Mortar Spraying Machine
Jining Bafang Mining Machinery Group Co., Ltd.- Type：Concrete Mixing Plant
- Shotcrete Type：Semi-Dry
- Machining Process：Hydraulic
- Structure：Spiral Type
- Productivity：50m²,h
- Feeding Height：50m
Base Info
- Vibrating Amplitude：2.6mm
- Certification：CE
- Condition：New
- Color：Yellow
- Transport Package：Wooden Case
- Specification：Total Weight: 380kg
- Trademark：Bafang
- Origin：Shandong China
- Production Capacity：1000pieces,Year
Description
Basic Info.
Vibrating Amplitude 2.6mm Certification CE Condition New Color Yellow Transport Package Wooden Case Specification Total Weight: 380kg Trademark Bafang Origin Shandong China Production Capacity 1000pieces/YearProduct Description
Factory direct sale wall cement mortar spraying machine320 mortar spraying machine is mainly used for building the inner and outer wall surface mixed with mortar, putty powder, refractory coating and pressure grouting.
This machine has the pressure, delivery height increases, delivery distance, flow and other characteristics.
| 1. Rated displacement | 30L/min |
| 2. Fixed work stress | 3MPa |
| 3. Total machine power | 8.5kw |
| 4. Main motor | 3phase,380 volt,5.5 kw |
| 5. Screw speed | 380rpm |
| 6.Air compressor displacement | 250L/min |
| 7.water pump displacement | 700L/h |
| 8. Maximum delivery distance | 50m |
| 9. Hopper volume | 120L |
| 10. Feeding height | 1000mm |
| 11. Pipe diameter | 25/32mm |
| 12. Tracheal diameter | 13mm |
| 13. Dimensions | 1240×680×1550mm |
| 14.Weight | 380kg |
