5ton Wheel Loader Front End Loader
SHANDONG VOCHAINS IMP & EXP CO., LTD.- After-sales Service：Instruct Installation and Operation
- Warranty：One Year
- Certification：ISO, CE
- Condition：New
- Rated Load：3-6t
- Transmission：Power
Base Info
- Model NO.：VCS956F
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
- Type：Medium-sized Loader
- Product：5ton Wheel Loader
- Operating Weight：16500kg
- Bucket Capacity：3.0m3
- Loader Rated Load：5000kg
- .Rated Power：162 Kw
- Key Word：Wheel Loader
- Model：Front End Loader Vcs956f
- Transport Package：Roll-on-Roll or Container.
- Specification：wheel loader
- Trademark：Vochains
- Origin：Shandong, China
- HS Code：8429510000
- Production Capacity：5000 Units , Year
Description
Performance
1
rated load
5000kg
2
overall weight
16500kg
3
rated bucket capacity
3m3-4.5m3
4
maximum tractive force
152KN
5
maximum breakout force
≥170KN
6
maximum grade ability
30ºC
7
maximum dump height
3150mm
8
maximum dump reach
1250mm
9
overall dimension (L×W×H)
8247×2960×3416mm
10
minimum turning radius
6640mm
Engine
11
model
Weichai SteyrWD10G220
12
type
lnline water cooling dry cylinder injection
13
No. of cylinder-bore/stroke
6-126×130mm
14
rated power
162kw--2400r/min
15
maximum torque
860N.m
16
min fuel-consume ratio
≤215g/kw.h
Transmission system
17
torque converter
YJ375
18
gearbox mode
Power shift normally engaged straight gear
19
gear shift
4 forward shift 4reverse shift
20
maximum speed
38km/h
Drive axles
21
main reducing spiral
bevel gear grade 1reduction
22
decelerating mode
planetary reduction,grade 1
23
wheel base (mm)
3200mm
24
wheel tread
2250mm
25
minimum ground clearance
450mm
Hydraulic system
26
system working pressure
18MPa
27
boom lifting time
5.95±0.2s
28
total time
10.95±0.5s
29
fuel tank capacity
300L
30
function of leveling automatically
yes
Brake system
31
service brake
air over hydraulic disc brake on 4 wheels
32
parking brake
manual parking brake
Tyre
33
type specification
23.5-25
34
front tyre pressure
0.4Mpa
35
rear tyre pressure
0.35Mpa
