Hoisting Machinery Hydraulic Truck Crane Qy25K-II 25ton
Evangel Industrial (Shanghai) Co., Ltd.- After-sales Service:Free Spare Parts
- Warranty:One Year
- Feature:Truck Crane
- Rated Loading Capacity:25 Ton
- Rated Lifting Moment:1010kn.M
- Max. Lifting Height:47.8m
Base Info
- Model NO.:QY25K-II
- Span:6m
- Model Number:Qy25k-II
- Condition:New
- Transport Package:Seaworthy Packing: Roro
- Specification:CE,ISO
- Origin:Jiangsu, China
- HS Code:87051091
- Production Capacity:100 PCS,Month
Description
Dimension
Unit
Overall length
mm
12650
Overall width
mm
2500
Overall height
mm
3380
Weight
Total weight in travel
kg
29400
Front axle load
kg
6200
Rear axle load
kg
23200
Power
Engine model
SC8DK280Q3 / WD615.329(domestic III)
Engine rated power
kW/(r/min)
206/2200 213/2200
Engine rated torque
N.m/(r/min)
1112/1400 1160/1400
Travel
Max. travel speed
km/h
75
Min. turning diameter
m
21.5
Min. ground clearance
mm
275
Approach angle
°
16
Departure angle
°
13
Max. grade ability
%
30
Fuel consumption for 100km
L
≈37
Main performance
Max. rated total lifting capacity
t
25
Min. rated working radius
mm
3000
Turning radius at turntable tail
m
3.065
Max. lifting torque
kN.m
1010
Base boom
m
10.7
Fully extended boom
m
34.19
Fully extended boom+jib
m
42.15
Longitudinal outrigger span
m
5.14
Lateral outrigger span
m
6
Working speed
Boom luffing time
s
75
Boom full extension time
s
100
Max. swing speed
r/min
≥2.5
Max. speed of main winch (single rope)
m/min
≥120
Max. speed of aux. winch (single rope)
m/min
≥120
Feature for Truck Crane QY25K-II :
Leading performance: the boom length in full extension is 42.15m, the performance leading in 5%. The grade ability is 30%, which make the machine have good road adaptability.
The unique U boom and plug-in boom head make the load-carrying capacity more balanced, and lift more smoothly.
The unique stretch and retract technique prevents the misoperation; the stretch and retract of the boom is safer and more reliable.
The control system is optimized by 8 patents; lifting, rotation, and luffing are easy and reliable.
Six unique technologies supply the quality assurance, and make the products keep a high value.
The innovative jib system adopts embedded block, plug-in boom head and octagon jib, which has excellent lifting performance and safe and reliable lifting work.
The unique stretch and retract technique avoids the bend of the core pipe and cylinder and the break of the boom caused by misoperation, improving the safety of the operations.
Eight patent techniques ensure the smooth, high efficiency and energy conservation of the lifting, rotation, and luffing systems.
Adopt the new hydraulic motor with big torque starting point, making the secondary lifting safer.
The torque limiter adopts colorful LCD display, realizing the intelligence of the failure diagnosis. The precision is ahead of the industry.
The humanity design makes the cab and control cab more spacious, and easy to operate.
Six unique manufacturing technologies ensure the high quality.
