• Model NO.：XE60DA
• Drive Type：Diesel Engine
• Bucket Capacity：0.1~0.5m³
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Model Number：Xe60ca
• Moving Type：Crawler Excavator
• Operating Weight：5960kg
• Maximum Digging Height：3945mm
• Maximum Digging Depth：3830mm
• Max Digging Radius：2460mm
• Transport Package：Seaworthy Packing: 40hq
• Specification：CE,ISO
• Origin：Jiangsu, China
• HS Code：84292090
• Production Capacity：100 PCS,Month

Model XE60CAOperating weightkg5960Standard bucket capacitym³0.09-0.23EngineEngine Model/4TNV94LDirect injection/√Four strokes/√Water cooling/√Turbo charged/×Air to air intercooler/×No. of cylinders/4Rated power/speedkw/rpm39.8/2200Max. torque/speedN.m214/1100DisplacementL3.054The main performanceTravel speedkm/h4.2/2.2Swing speedr/min11Max. gradeability/30°Ground pressurekPa32.5Max.Bucket digging force kN48.3Max.arm crowd force kN32.5Hydraulic systemMain pump/Oil capacityHydraulic tank capacityL85Engine lubricationL12A Overall lengthmm5960Overall dimensionsB Overall widthmm1920C Overall heightmm2585D Overall width of upperstructuremm1780E Track lengthmm2540F Overall width of undercarriagemm1920G  crawer widthmm400H Dozer black(width/height)mm1920×340I Tumbler distancemm1990J Crawer gaugemm1550K Clearance under counter weightmm710L Ground clearancemm385M Min.tail swing radiusmm1660A Max. digging heightmm5630Working rangeB Max. dumping heightmm3945C Max. digging depthmm3830E Max. vertical wall digging depthmm2680F Max. digging reachmm6130G Min. swing radiusmm2460H Max.dozer lifting heightmm390I Max.dozer cutting depthmm560 Angle of arm deflection Degree/
